Electro/Hot Dipped galvanized welded iron wire mesh Factory:

About Company:

Zhengzhou Aobest Electronic Technology Co., Ltd is a top manufacturer for Power cables and Electric wires for more than 20 years in China.

Our main products include as belows:

1: AAC, ACSR, AAAC, guy wire

2: PVC insulated power cables.
3: XLPE insulated power cables
4: Armored power cables
5: Overhead insulated cables
6: Electric wires
7: Control cables and other instrument cables

initpintu_

Product Description

1.Material:  iron wire, steel wire,SAE1006/1008,Q195/235 SAE1050/1065



2.Wire diameter: BWG6-BWG36



3.T/S(kg/mm2):  30-50



4.Surface treatment: electro-galvanized, hot galvanized



5.Characteristics:smooth,well-proportioned zinc coating



6.Usage:   cable,arts,binding wire,building wire,highway barrier.etc



7.Package:

 (1)    On spools (wooden spool, plastic spool, cardboard spool)

 (2)    In coils (0.275kg-150kg/coil)

 (3)    Big coils (400-1000kg/coil)

 (4)    In cartons(specially for galvanized straight cut wire, length 0.3m-6m)

 The standard packing forms are inside wrapped plastic film outside woven bag, inside wrap

ped plastic film outside hessian cloth, wrapped with thick plastic cloth etc.

 HTB1ROt1HpXXXXcyXpXXq6xXFXXXh HTB1CInDHXXXXXXOXFXXq6xXFXXXe

8.Zinc coating:

 For hot dipped galvanized wire can be from 40g/m2 --- 300g/m2.

 For the Electro galvanized iron wire can be from 8g/m2 --- 18g/m2.



9.Processing: it is drawn from low carbon steel wire, then through acid washing and

rusting removing as well as annealing and coiling.

  acsr17

 SWG
(MM )
BWG
(MM )
  SWG
(MM)
BWG
(MM)
  SWG
(MM )
BWG
(MM )

08.2308.6360.340171.4221.4730.058340.2340.1780.007
17.6207.6200.300181.2191.2450.049350.2130.1270.005
27.0107.2140.284191.0161.0670.042360.1930.1020.004
36.4016.5790.259200.9140.8890.035370.173*0.0068
45.8936.0450.238210.8130.8130.032380.152*0.0060
55.3855.5880.220220.7110.7110.028390.132*0.0052
64.8775.1560.203230.6100.6350.025400.122*0.0048
74.4704.5720.180240.5590.5590.022410.112*0.0044
84.0644.1910.165250.5080.5080.020420.102*0.0040
93.6583.7590.148260.4570.4570.018430.091*0.0036
103.2513.4040.134270.4170.4060.016440.081*0.0032
112.9463.0480.120280.3760.3560.014450.071*0.0028
122.6422.7690.109290.3450.3300.013460.061*0.0024
132.3372.4130.095300.3150.3050.012470.051*0.0020
142.0322.1080.083310.2950.2540.010480.041*0.0016
151.8291.8290.072320.2740.2290.009490.031*0.0012
161.6261.6510.065330.2540.2030.008500.025*0.0010
Packaging & Shipping

1:standard export  wooden drum/steel wooden drum

2: upon your request

initpintu 11

Our Services

Our company is a professional supplier of various kinds of cables for over 10 years.

The quality of our products are guaranteed. They are all with CCC, CE, CB and RoHS certificates.

  •  Any inquiries will be replied within 24 hours.
  •  OEM/ODM available.

     1) Printing your logo on the cable.

     2) Printing your logo on the pull box, wooden drum according to your design

     3) Any your idea on cable, packing box are available.

  • High quality, reasonable and competitive price, fast lead time.
  •  Good after-Sale Service.

    1) All products will have been strictly Quality Checked in house before packing.

    2) All products will be well packed before shipping.

  •  Faster delivery.:Sample order in stock, and 3-7 days for bulk production.
  • Strong technical support (technical data, drawing, etc.)
  •  Free sample is available with economic express fee.

Payment:We can accept payment methods: L/C, T/T, Western Union,other payment can negotiation.

Company Information

About Us:

Zhengzhou Aobest Electronic Technology Co., Ltd. is a professional company, located in Zhengzhou, China. We provide power cables and wires.

Our main products: High and low voltage XLPE insulated Cables, PVC insulated cables, steel wire armored cables, steel tape armored cables, ABC cables, Overhead insulated cables, AAC, AAAC & ACSR cables, Copper wires, Galvanized steel wire strands, PVC insulated wires and flexible wires, Rubber insulated cables, underground cables, control cables, aluminum sheets, etc.

The international standard we can follow: ASTM, IEC, BS, GB, DIN and AS/NZS standards and other standards.

We can provide OEC service.

Since our establishment, we have insisted on the tenet of "scientific management" and tried our best to improve product quality. We control every chain especially the process of production strictly, ensuring the unqualified raw materials and semi-finished products not enter into the next operation. We guarantee that all the finished products meet the requirements of our clients.

Our sales networks cover the whole world. Our products sell well in Australia, the Philippines, Vietnam, Thailand, Myanmar, Kenya, South Africa, Nigeria, Tanzania, the USA, Singapore, the UK, Italy, Bolivia, Chile and European countries. Our company has established long-term cooperation and friendship with clients worldwide.
