Product Overview

Description

 1

UL1330/1331 FEP Insulation Wire
(UL series:UL1330, UL1331, UL1332,1333,1709,1710,1726,1727,1857....)
Standard:UL758

Nominal Voltage:600V
Temperature Range:-100°C~+200°C (1330)
                  -100°C~+150°C (1331)
O.D.Tolerance:±0.10mm
Testing Voltage:2500V
Conductor: Tinned Copper /bare copper/silverd copper
Insulator: FEP

Colours:White-Blue-Red-Black-Brown-Yellow-Green-Transparent-Yellow/Green
Application: For internal wiring(hook-up wire) of various household appliances, lighting appliances, electronic devices, temperature sensor, etc.

Conductor Insulator Electrical Characteristic
 AWG               Weight
Diameter Nominal Thickness Over diameter Realst,maxCuc,c 20°C Intens.Maxl170°C
NO. φmm φmm φmm φmm Ω/km AMR Kg/km
30 1 0.254 0.25 0.2 0.65 377 0.8 0.9
7 0.10 0.30 0.225 0.7 1.25
28 1 0.32 0.32 0.250 0.75 237 1 1.45
7 0.12 0.36 0.275 0.8 1.55
26 1 0.40 0.40 0.305 1.05 152 1.16 3.0
7 0.16 0.48 0.305 1.1 3.03
24 1 0.50 0.50 0.305 1.1 93.3 3.0 3.44
7 0.20 0.60 0.305 1.2 4.00
19 0.12 0.60 0.305 1.2 3.97
22 1 0.60 0.60 0.305 1.3 56.1 5.0 5.1
7 0.254 0.76 0.305 1.4 5.81
19 0.15 0.75 0.305 1.4 5.65
20 1 0.80 0.80 0.305 1.5 34.6 7.0 7.2
7 0.31 0.96 0.305 1.6 8.25
19 0.185 0.93 0.305 1.6 7.87
18 1 1.0 1.0 0.305 1.7 22.2 11 9.95
7 0.39 1.17 0.305 1.8 11.3
19 0.235 1.17 0.305 1.8 11.1
30 0.18 1.13 0.305 1.8 10.8
17 19 0.26 1.3 0.305 1.93 17.7 14 13.3
16 1 1.3 1.3 0.305 1.95 16.6 19 15.8
7 0.49 1.47 0.305 2.15 16.8
19 0.30 1.5 0.305 2.2 17.5
14 19 0.37 1.85 0.305 2.52 8.78 22 24.9
12 19 0.47 2.35 0.305 3.05 5.53 30 38.2
10 37 0.43 3.01 0.305 3.7 3.95 45 59.9
