400V/50A high frequency DC switching power supply, LED light, new energy vehicle controller aging test power supply

Share on:

Price:RUB 213,504.89
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

400V/50A high frequency DC switching power supply, LED light, new energy vehicle controller aging test power supply





Basic parameters
Product name 400V/50A new energy vehicle controller aging test power supply
input voltage

Three-phase AC380V (support Single-phase and voltage customization)

output voltage

0~400V adjustable  (Support customer customization)

Output current 0~50A adjustable  (Support customer customization)
The output power 20KW
Work efficiency ≥90%
Power factor ≥93%
Adjustment accuracy ≤1%
cooling method Forced air cooling
ambient temperature

-15~45°C

Ambient humidity ≤85%(No condensation)



Other parameters
Output characteristic Constant voltage or current can be selected
Protection mode Automatic fault protection, including overheating, overvoltage, overcurrent, short circuit, etc.
The output shows Digital Display of LED Voltmeter and Amperometer
Insulation strength Input and output, input and chassis: AC2200V, 10mA, 1 minute
insulation resistance Input and Output, Input and Shell, Output and Shell: > 20MΩ
insulation class Level B
Protection level IP20
Outline size Shell size:650 *450 *705 mm
Applicable load It can simulate the battery of a new energy car.Used for testing and aging of new energy vehicle motor controllers ,DC motors and new energy electric vehicles. It can be used to replace automotive batteries and provide efficient ,low cost and accurate test solutions.






























Certification

ce001_



FAQ

————————————————

1Q:Aer you a manufacturer or a trading company?

 A:We are a manufacturer,and this is our factory's address:NO.3,Xinye Yixiang,Chenchung in dustrial zone,Qiaonan street,Panyu district,Guangzhou city,Guangdong Province,China.



2Q:Do you accept OEM?

 A:Yes,all of our products can be customized.



3Q:What's your MOQ?

 A:1piece is OK



4Q:What's the lead time?

 A:It deoends,generally it's with in 5 business days for 1-2 piece.



5Q:What's your warranty?

 A:One year.



6Q:What's your payment?

 A:T/T,L/C are both acceptable.



contact details
e-mail  2863184072 @.com
telephone / fax  +86-13925093308/+86-02033124880
qq  1605779413
WeChat  13925093308



400V/50A LED lamp, new energy vehicle controller aging test power supply
*The power supply can be converted to constant voltage or constant current, and the voltage and current can be continuously adjusted from zero to the highest rated value. The power supply uses LC filtering technology. The output waveform is good, the current ripple coefficient is small, and the current distribution is good. The output voltage and current range are large, the response speed is fast, the stability and accuracy are high, and the detection data is accurate.
*Suitable for LED lamp, car lamp aging test, inverter aging test, car player test, laboratory test of universities or research institutes, etc.
*Can be customized according to customer requirements
