Product Overview

Description

Main Technical Data
Number of roller
2-5 layers
Tube diameter
6mm --12mm
Tube wall-thickness
0.3-2 mm
Cutting Length
120-950mm 5 cutters
120-1050mm 6 cutters
Winding head
2
Power
5.9 KW
Cutter system
Multi-blades 5 sets / 6sets
Gluing system
Single /Double sides
Operator
1-2 person
Winding speed
40--60 m/min
Speed control
Frequency
Working Air Pressure
0.6Mpa
Power Supply
380V/3Phase/50Hz
Measurement
5600*1600*1750mm
Working Space
8000mm * 6000mm*1800mm
Weight
1500kgs


Main Features

1) Simple structure, easy in installation and maintation.


2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.


3) Servo motor synchronism tracking cutting system.


4) Running in a high way with maximum speed of 45~100 meters/min


5) Original paper straw machine designer.


Product Application

UNL-XG50 Paper Drinking Straw Making Machine is special for paper drinking straws production. Equipped with Numerical and Multi-blades Cutting System. PLC controlling system with automatic operation. Synchronous cutting system controlled by servo motor. It means the cutting part moves together with paper tubes and cutting in a high precision. Adopt with Multi-cutters online cutting system. Paper straws can be finished in one-step.
