Europe design ESR 1300X1.5E Electric Slip Rolling Machine Metal Small Electric Slip Roll Machine

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description


Electric Slip Rolling Machine Metal Small ESR-1300X1.5E Electric Slip Roll Machine for sale




1.Electric Slip Roll Machine
2. Asymmetrical roll bending machine with 3-rolls
3. High strength steel rolls

1. Fixed top roller, adjustable lower and rear rollers
2. Standard series wire core groove
3. Top roll swing out across cam lock
4. Supplied with conical bending feature
5. The electric slip roll not only reels but also can cone materials
6. It can roll the round bar steels whose specifications are Φ6, Φ8, Φ10 and so on.
7. The 24V pedal switch can smooth the operation
8. The safety mechanism of electric slip roll is in line with the CE standard.
Main technical parameter:


ESR1300X1.5E LOGO.jpg






































ModelMax.thickness (mm)Max.width
(mm)
Motor power
(Kw)
Packing
dimension(cm)
N.W./G.W.
(kg)
ESR-1300X1.51.513000.75115X50X69166/210
ESR-1020X22.010200.75155X50X69200/240
ESR-1300X1.5E1.513000.75180X50X69223/260
