Manual Mass Shelf Mobile Filing Cabinet Compact Shelving System

Share on:


Price:RUB 6,520.35
Price in USD:Details

Quantity:

Add to Cart
  • add to wishlist

Product Overview

Description

Shelf body
Stand Column
Cold-roll steel
1.5mm
GB708
Partition
Whole body partition flange 25mm (reinforcing rib under the partition)
Cold-roll steel
1.0mm
GB708
Side plate
Cold-roll steel
1.0mm
GB708
Upper cover plate
(whole body side plate dimension 300*100mm)
Cold-roll steel
1.0mm
GB708
Panel
Cold-roll steel
1.0mm
GB708
chassis
Main beam and whole frame board(every wheeolk frame board have six; 55mm beam bush hold. every hole have sealing
Hot rolled steel plate
3.0mm
GB710
pathway
Rail
High quality steel plate
Solid square tube
GB710
Rail box
High quality steel plate
26*95mm Thickness 3.0
GB710
Pathway
High quality steel plate
50*185mm Thickness 3.0
GB710
Transmission part
Handle crank
ZG45
Bothway overload clutch double axis transmission
GB1285
Transmission shaft
Solid core 45 steel
Φ20
GB699
Linkage rail
Seamless steel tube
Φ20*2.5
GB699
Bearing
Precision bearing
HR6204
GB/T307.9-2005
Chain wheel
ZG45
GB1135
Chain
FR420
Φ8.5, pitch 12.7 breaking force 1800kg
GB1244
Idler wheel
HT20-40
Cast iron
Gb11351
Sealing rubber strip
Magnetic fluid sealant
Dust shield
Cold-roll steel
1.0
Gb710
Barb
Hot rolled steel plate
3.0mm
Gb711
