high speed multi-cutters straw paper making machine
- Category: Straw Making Machines >>>
- Supplier: Zhejiang,Hongshuo,Import,And,Export,Co.,Ltd.
Share on:
Product Overview
Description
FEATURES AT A GLANCE
(1)Save space and time.
(2) The machine has sterilization function.
(3) Have no problems caused by weather and glue.
(4) The paper straws can withstand in high temperature and be degradable.
(5) The product. loss rate is greatly reduced.
(6)The hardness increases with the same thickness raw materials.
(7) The whole machine adopts servo motor.
(8) It is suitable for double-use models with glue and no glue.
(2) The machine has sterilization function.
(3) Have no problems caused by weather and glue.
(4) The paper straws can withstand in high temperature and be degradable.
(5) The product. loss rate is greatly reduced.
(6)The hardness increases with the same thickness raw materials.
(7) The whole machine adopts servo motor.
(8) It is suitable for double-use models with glue and no glue.
Certifications
PRODUCT SPECIFICATIONS
Raw Material | Pure wooden pulp paper |
Paper Layers | 3-4 layers |
Paper Thickness(from inside to outside) | 120g/m²,120g/m²,60g/m² |
Tube Thickness | 0.3-2mm |
Running Speed | 40-100m/min |
Tube Size | 4.5-12mm |
Cutting System | servo motors,8 sets knives |
Cutting Length | 70-1050mm |
Power Source | 380V, 50Hz |
Operation Person | 1-2person |
Paper Roll Bracket | 1600*2000*1100mm |
Main Part | 2300*860*1270mm |
Collection Part | 1900*970*1770mm |
Weight | 1400kg |
PRODUCT CONFIGURATION
Main Motor | co-trust(1.5kw) |
Drive | co-trust |
Touch Panel | siemens |
Servo Motor | co-trust |
Bearing | HRB |
Electronic components | Omron |
Pneumatic parts | Airtag |
Product packaging
FAQ
Q1. What kind of straw your machine can make?
A: Our machine can make different size straw, or you can also supply your sample.
Q2. Do you provide customized machine?
A: Please share your requirement of the machine, we have experienced engineer to support.
Q3. What about the payment term?
A: 30% deposit in advance, and 70% balance payment before delivery.
Q4. What is the package of machine?
A: Stretch film packing with wooden pallet or wooden case as request.
Q5. Are you trading company or manufacturer?
A: We are one of the leading manufacturer of paper product machinery in China.
A: Our machine can make different size straw, or you can also supply your sample.
Q2. Do you provide customized machine?
A: Please share your requirement of the machine, we have experienced engineer to support.
Q3. What about the payment term?
A: 30% deposit in advance, and 70% balance payment before delivery.
Q4. What is the package of machine?
A: Stretch film packing with wooden pallet or wooden case as request.
Q5. Are you trading company or manufacturer?
A: We are one of the leading manufacturer of paper product machinery in China.
