high speed multi-cutters straw paper making machine

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description



FEATURES AT A GLANCE


(1)Save space and time.
(2) The machine has sterilization function.
(3) Have no problems caused by weather and glue.
(4) The paper straws can withstand in high temperature and be degradable.
(5) The product. loss rate is greatly reduced.
(6)The hardness increases with the same thickness raw materials.
(7) The whole machine adopts servo motor.
(8) It is suitable for double-use models with glue and no glue.



Certifications






PRODUCT SPECIFICATIONS


Raw Material
Pure wooden pulp paper
Paper Layers
3-4 layers
Paper Thickness(from inside to outside)
120g/m²,120g/m²,60g/m²
Tube Thickness
0.3-2mm
Running Speed
40-100m/min
Tube Size
4.5-12mm
Cutting System
servo motors,8 sets knives
Cutting Length
70-1050mm
Power Source
380V, 50Hz
Operation Person
1-2person
Paper Roll Bracket
1600*2000*1100mm
Main Part
2300*860*1270mm
Collection Part
1900*970*1770mm
Weight
1400kg


PRODUCT CONFIGURATION


Main Motor
co-trust(1.5kw)
Drive
co-trust
Touch Panel
siemens
Servo Motor
co-trust
Bearing
HRB
Electronic components
Omron
Pneumatic parts
Airtag


Product packaging




FAQ


Q1. What kind of straw your machine can make?
A: Our machine can make different size straw, or you can also supply your sample.

Q2. Do you provide customized machine?
A: Please share your requirement of the machine, we have experienced engineer to support.

Q3. What about the payment term?
A: 30% deposit in advance, and 70% balance payment before delivery.

Q4. What is the package of machine?
A: Stretch film packing with wooden pallet or wooden case as request.

Q5. Are you trading company or manufacturer?
A: We are one of the leading manufacturer of paper product machinery in China.
