Product Overview

Description



Product Overview


· Advantages

☺ Easy to install and maintain.

☺ Food grade SUS304 stainless steel to ensure that the ice is edible.

☺ PLC intelligent control, fully automatic production, without manual operation.

☺ Automatic laser welding, low failure rate.

☺ Special water system design, uniform thickness, clear and pure ice.

☺ You can choose manual or automatic packaging system.


· Product Features
☺ The shape of the ice cube is a hollow tube with irregular length, and the diameter of the inner hole is 5mm ~ 15mm.
☺ The ice with the smallest contact area and the best melting resistance.
☺ Combining water purification technology with tube ice production, the tube ice produced is edible ice.
☺ Our company has tube ice machines with external diameters of 22mm, 28mm and 35mm for customers to choose from.


Features At A Glance


Why Choose Us?
Superior R&D team

1. latest technology on the refrigeration system which reduce the electricity consumption
2. special design on the ice defrosting
3. CBFI's unique tube ice machine evaporator process 4. special design for the ice cutter.
Mature pre-sales and after-sales service
1. It can make different size tube ice.
2. Localized after-sales service in some countries.
3. Provide Installation or After-sales Service Global Wide.
Easy Operation
Fully automatic, easy installation, easy operation, easy maintenance














Tube Ice Applications
The tube ice made by the equipment is transparent and beautiful.
Applied to
Cold drinkings
Restaurants, bars, café Supermarkets and Convenience Store
Food processings
etc.


Product Parameters


Model
Daily output
(T/24 h)
Compressor
Power
Fan Power for Cooling Tower
Cooling
Pump Power
Unit size (L*W*H mm)
(Integrated Type)
Unit N.W.(kg)
TV 10
1
4.1 kw
0.25 kw
1.1 kw
1100*900*1780
900
TV 20
2
7.44 kw
0.25 kw
1.5 kw
1250*1000*1950
1200
TV 30
3
10 kw
0.55 kw
1.5 kw
1300*1100*2200
1500
TV 50
5
19.9 kw
0.55 kw
2.5 kw
1600*1400*2250
1800
Model
Daily output
(T/24 h)
Compressor
Power
Fan Power for Cooling Tower
Cooling
Pump Power
Unit size (L*W*H mm)
(Integrated Type)
Unit N.W.(kg)
Main Host
Brine Tank
TV 100
10
27.9 kw
1.5 kw
4 kw
1900*1600*1850
1200*1200*3390
3500
TV 100+
10
39.8 kw
1.5 kw
4 kw
2400*1700*2000
1200*1200*3390
3700
TV 150
15
46.4 kw
1.5 kw
5 kw
2700*2000*2200
1500*1200*4250
4250
TV 200
20
55.7 kw
2.2 kw
7.5 kw
2800*2200*2500
1500*1200*4700
6500
TV 300
30
83.6 kw
2.2 kw
7.5 kw
3100*2200*2500
1800*1500*5700
7200
TV 400
40
111.4 kw
2.2 kw
11 kw
3900*2250*2500
2000*1500*6800
8300
TV 500
50
139.3 kw
3.75 kw
15 kw
4500*2250*2500
2200*1800*7200
9500
1. Compressor brand: Bitzer /Franscold ; Refrigerant: R 22/ R 404 A; Cooling Method: water cooling / air cooling.
2.Power supply:voltage 380V/3P/50Hz(for non-standard voltage, unit configuration needs to be calculated separately ).
3.Operating conditions: T (water supply):20℃ , T (ambient): 32℃, T(condensing):40℃, T (evaporating):-12℃.
4.(Note: The actual ice production varies due to the influence of water supply temperature and ambient temperature.)
5.(The final interpretation of the above mentioned parameters is in Icesource, there will be no further notice, if there any
technical change. )


The main reason for the good quality of the ice machine produced by our company is that the compressor, condenser, expansion valve, PLC controller and other important parts are imported. The equipment has good performance and strong anti-interference ability. The external environment has an impact on the output and ice. The quality of the product has little effect.A variety of models can meet the needs of customers at different levels.


Successful Project




China's first 30 ton ammonia machine case in Europe
The customer is one of the largest fully automatic ice factories in Europe. In order to meet the ice demand of the market, the customer choose to cooperate with CBFI, so why CBFI? *Because CBFI can provide equipment that meets European CE import and installation standards, it is also the only manufacturer in China that can produce such equipment. *Compared with machines of the same quality in Europe, the price has an absolute advantage, reducing customer costs, allowing customers to recover costs in the shortest time and obtain profits. With the assistance of CBFI professional engineers, the machine was successfully installed and the ice tube have been sold to the European market.




Our Services


Installation:
1). Installing by the user: we will tested and install well the machine before shipment, all necessary spare parts, operation
manual and CD are provided to guide the installation.

2).Installing by our engineers:
(1) We can send our engineer to assist the installation and provide technical support and train your workers. The end-user provide accommodation and round-trip ticket for our engineer.

(2) Before our engineer arrived in your site, the installation place, electricity, water and installation tools should be ready.
Meanwhile, we will provide you a Tool List with the machine when delivery.

(3) All spare parts are provided according to our standard. During installation period, any shortage of parts due to the actual installation site, the buyer is required to afford the cost, such as water pipes.

(4) 2~ 3 workers are required to assist the installation for big project.

Guarantee Period: During 12 months after selling, maintenance and parts free of charge
