automatic change 100-600mm size Cable tray roll forming machine

Share on:

Price:RUB 7,422,030.00
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Cable tray roll forming machine

Hot Sales

-------------------------------------------------------------------

Detailed Product Description



Roll Forming Machine

Cable Tray Roll Forming Machine

Cable Ladder Roll Forming Machine

---------------------------------------------------------------------

With full and special experinence, we also can do a custom roll forming machine, i.e. we can design the roll forming machine just according to your profile drawing and specification.Send your profile drawing and detailed specification to us. Our engineers will design the roll forming machine for you.

After roll formed by this roll forming machine, the surface will be very smooth and beautiful without any scratch on surface.

Rollforming process: uncoiler, rollforming, cut to length. (punching also can be added if needed.)

Fully Automatic Control System with PLC.

New Type! Cable tray roll forming machine

Easy operation: Key in the length and quantity on the control panel.





Please see the technical parameter:

1. Technique parameters of the processing line



         Main parameters of cable tray machine

1

Suitable to process

Color steel plate, galvanized strip, aluminum coils and etc.

2

Width of the product

100-600mm

3

Roller station

18-22 rows

4

Thickness of feeding material

1.0-2.0 mm

5

Productivity

8-12m/min

6

Rollers' material

45# carbon steel

7

Diameter of shaft

90mm

8

Weight

About 9.0 T

9

Size of the machine

9.0*1.3*1.5mm

10

Voltage

380V 50Hz 3Phase

11

Main power

11 kw*2

12

Cutting power

4kw

13

Tray size

30-100mm height

50-600mm width

15-20mm edge




.jpg


New Type! Cable tray roll forming machine

New Type! Cable tray roll forming machine

What's more, equipment can be specially designed and
manufactured at customers' requirements.
Fine quality as well as low price.This new product is
to the taste of world market.
Products Warranty: 20 months, and we will provide
the technical support for the whole life of the equipment.

Packaging & Shipping


Our Services


Guarantee:

20 Months guarantee. if some part of the machine is broken. we will supply the best part,but if the damaged parts due to operate error,buyer will pay for the shipping fee.

After-sale service:

We sent technician to your country to fix the machine.the buyer shoule bear all the cost includng:visa,roundtrip ticket and suitable accommodation,also buyer should pay the salary 100USD/DAY.
