High quality soundproof waterproof SIP acoustic wall panel

Share on:


Price:RUB 395.24 - RUB 790.47
Price in USD:Details

Quantity:

Add to Cart
  • add to wishlist

Product Overview

Description



  WELCOME TO VISIT US!




High quality soundproof waterproof SIP acoustic wall panel



General Introduction

_

Terasun high quality soundproof waterproof SIP acoustic wall panel is know as our Terasun TSM SIP Series, a composite building material. They consist of a sandwich of two layers of structural board with an insulation foam in between. The   acoustic wal panel sip panel skins are TSM board----Terasun Silicate Magnesium Board. Insulation core can be Expanded Polystyrene (EPS) or Extruded Polystyrene (XPS).



Terasun acoustic wall panel is characteristic of soundproof, waterproof, fireproof and other great properties.



The panel skin of the acoustic wall panel is our TSM board---Terasun Silicate Magnesium Board, is newly developed environmental friendly, energy-saving building material.



Terasun TSM SIP---(acoustic wall panel), your best choice for construction and decoration.



Below is detail information for the panel skin---TSM and panel core---EPS:



Technical Data



Panel Skin---TSM

Commodity Terasun Silicate Magnesium Board---TSM
Raw Material Foam particles, cement, plant fiber, glass fiber cloth, non-woven fabrics, etc
Density ≤ 0.95  g/cm³
Size 1220*2440mm or 1200*2400mm Customerization is available
Thickness 6~20mm
Moisture Content ≤ 12%
Fire Rating Test Class A1 incombustible material
Moisture Movement ≤0.12%
Bending Strength ≥  8.5 Mpa
Maximum Service Temperature 1200  °C
Water Permeability  No water vapor after 24 hours' test
Permanent Linear Shrinkage ≤ 0.4%
Refractoriness  4H
Coefficient of Thermal Conductivity   ≤0.2 W/MK
Color Grey
Features / Merits WATERPROOF; fireproof; termite proof; light-wight; flexional; easily to be shaped, perforated, bended; long service life; environmental friendly, etc



Panel Core---EPS

Standard Size 1200*2400/3000mm; 1220*2440;
Thickness 76mm, 114mm, 165mm
Density

18 KG/M3  or 27KG/M3

Maximum Length: 3010mm, Maximun Width: 1220.
Custome specification is available upon request



Features



Pane Skin---TSM: Class A1 non-combustible; Much wasier to be cut, moved and decorated; Contains no asbestos or formaldehyde; Environmental friendly; No harm to human health; Waterprooy, Fireproof etc.



Panel Core--EPS: Over 80% of the SIP panels installed are EPS. EPS core material is widely available. It is easy to modify on sight and most sip installers have experience dealing with EPS. It's also the least expensive option in terms of material cost.



Detailed Images



2  002 .jpg



Packaging & Shipping



Packing and Loadng

Usually packed with strong wooden pallets, but packed according to customers' request is also available.

Shipping and Delivery

1.For large quantity or big orders, only transportation by sea is available.

2.For medium quantity or small orders, all transportation are available.

transportation



Advantages to Use Terasun Sandwich Panel





Architectural Benefits Construction Process Benefits
High quality construction method Easy to construct, with short learning curve
Comfortably warm, clean and quiet. 60% shorter construction time
Cost Benefits Increase builders' production capacity
Equal or lower first cost Environmental Benefits
Lower long term operating costs 50% less framing lumber

Incentives available from utility service provider

for energy efficient design

50% more energy efficient
Lower maintenance costs Less construction waste



Main Usages



F~9CJ3IR(P`$R5XOFN$9N60



Terasun high quality soundproof waterproof SIP acoustic wall panel, is of high quality and with great performance. Terasun sandwich panel are prefabricated systems used primarily for walls and roofs. It employs composite materials, reduce waste through modular construction methods, achieve high insulation values, and may be used instead of many conventional building methods. They can be widely used in residential housing and commercial etc.



Applications



Residential Housing

SIP Residential



Commercial Buidling

SIP Commercial



Installation



Terasun high quality soundproof waterproof SIP acoustic wall panel is quite easy and fast to install.



SIP SIP




About Us



Company Introduction

ZheJiang Terasun Air Duct Co., Ltd is a professional company which is specialized in manufacturing air ducts and composite boards, we are a leader in R&D new type environment friendly energy-saving building materials and composite materials.



Our company is established in 1989, and we have independently researched and developed over ten new types of building material products,and have obtained 18 national patents (including 3 patents for invention). Our company's R&D and technical ability keep ahead in the world, and our company is honored as "ZheJiang Province High-tech Enterprise'' and ''ZheJiang Patent Pliot Enterprise". Our company also is in charge of drafting two national standards about glass magnesium composite air ducts.



All of our TERASUN Boards are 100% without asbestos & formaldehyde, and have already passed the test of National Building Material Quality and Inspection Center, which are energy-saving and enrironmenal friendly building materials and advocated by our country. TERASUN boards industry fully implements the ISO9001 and ISO14000 quality control syestem, strictly control products' quality and satisfy customers' requirements of different applications in building, decoration and contruction.

Enterprise Honor

Enterprise Honor 3

Why Us ?

1.Our ultimate goal is to make every customer satisfied, providing you with right products and come up with correct solutions.

2. Your inquiries will be replied in 24 hours.

3. With professional R&D team and technicists, our experienced sales will answer all your doubts and questions in fluent English.

4. Shipping will be the most economical and freight cost is informed in advance for your referrence. Decision for the shipping terms is up to you.

5. Delivery time is guaranteed. You will be informed with new delivery messages if there is any updates.

6. As a professional manufactory, products specification and pakage can be customized. Pls free to contact us on this.

7. Prompt delivery & professional after-sales service are our priority.

Waiting for Your Kind Inquiry !
