Price:RUB 759,012.00 - RUB 7,590,120.00
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Specifications of More than 99.95% high purity molybdenum plate:

1. Grade: Mo1 Mo3G
2. Temper: H ½H 1/4H soft
3. Thickness: 1mm-10mm
4. Width: 50mm-600mm
5. Purity: Mo≥99.95%
6. Density: >10.2g/cm³
7. Standard: ASTM B386-03
8. Single weight:0kg~11.5kg
9. Normal Dimension:
     7.0kg: 25×150×195/mm
     11.5kg:35×150×195/mm

Chemical Composition:

Mo(%)Mo-1Mo-2Mo-3
99.9599.9599.95
Other Element Content(%) ≤Pb0.001
Bi0.001
Sn0.001
Sd0.001
Cd0.001
Fe0.0050.0060.01
Ni0.0020.0030.005
Al0.0020.0020.005
Si0.0030.0030.01
Ca0.0020.0020.005
Mg0.0010.0020.003
P0.0010.0010.002
C0.0050.0080.01
O0.0030.0050.05
N0.0010.003-



Features of Molybdenum Plate

>High temperature
>Strong corrosion resistance

Applications of Molybdenum Plate:

• Electrodes
• Furnace tools and parts
• Electronic parts
• Nuclear energy and missile and aircraft parts
• Semiconductor industries
• Sapphire grower cover plate
• Heating band
• Heating element of high temperature furnace
• Heating element of insulating layers
• Lighting sources parts
• High temperature shields and boats
• High temperature containers

Molybdenum Plate-5.jpg

Impurity content of Molybdenum Plate:

GradeThe impurity (max.,%)
FeNiAlSiMgCNO
Mo-10.010.0050.0020.010.0050.010.0030.008
Mo-20.010.0050.0050.010.0050.010.0030.02


Tolerance of Thickness:

ThicknessMax. WidthMax. LengthThickness Tolerance
0.090" ~ 0.200"30"114"+/- 0.008"
0.200" ~ 0.250"24"84"+/- 2%
0.250" ~ 0.500"24"42"+/- 2%
>0.500"24"-+/- 2%





Molybdenum Plate-3.jpg
