Product Overview

Description





Item name

Light steel structure prefabricated warehouse

Main structure

Material

Q345B, Q235B



Column and beam

Welded H section steel, Hot roll H section steel, Box column is also available, Circle column



Surface processing

Paint or hot dip galvanized



Connection

High strength bolt Grade 10.9s

Substructure

Purlin

C channel or Z channel, steel Q235B, galvanized



Angle brace

L50x4, Steel Q235B, Paint or hot dip galvanized



Cross bracing

Dia.20 round bar or L75x6 angle brace, Steel Q235B, Paint or hot dip galvanized



Tie bar

Dia.76*2.5 - 121*3 round pipe, Steel Q235B, Paint or hot dip galvanized



Purlin brace

Dia.12 round bar, Steel Q235B, Paint or hot dip galvanized



Connection

Ordinary bolt

Roof and Wall

Panel

(50mm, 75mm, 100mm, 150mm) Sandwich panel or (0.3mm – 1.2mm) corrugated GI color steel sheet



Transparent skylight

1.2mm FRP



Accessories

Sealant, self-tapping screw, rivet etc.



Edge cover

Made of color steel sheet



Gutter

Made of steel sheet thickness 0.5mm



Rainspout

PVC pipe

Others

Ventilator

Unpowered axial-flow ventilator, electrical fan or clerestory



Door

Pedestrian door, Electric rolling door/sliding door/ lifting door



Window

plastic steel window, Alu. alloy window



Crane

With or without crane, ranging from 2 tons to 20 tons
