Product Overview

Description





Product Description

 Retractable Fall Arrester Block



Item No.

GJ Series
Features

- Main Cable: Galvanized steel wire rope

- Shell Material: Aluminum alloy

- Cable Diameter: 4mm

- Max. Load 150Kg

- Self Weight: 3-20Kg

PerformanceLocking speed: 1.0 m/s
Compliance Standard

GB2454-2009 << TEST METHOD FOR PERSONAL FALL PROTECTION SYSTEMS>>

MOQ1 unit
Warranty1 Year
PaymentL/C, T/T, Western Union
Packing DetailsIron Pack
Diagrammatic Drawing1.jpg

-2



The GJ Series Retractable Fall Arrester is designed to restrain the person from vertical falls while allowing them freedom of movement. It also can be called fall arrester. The retracting feature eliminates tripping hazards while the inertia-locking mechanism arrests a fall within inches of activation.



The retractor connects to the fixed sling of the person which is parallel to the hook of the crane and must be attached to an approved point which can be endured 23KN.



Fall Arrester is made of sealed aluminum Jacket or Plastic shell, automatically controlled by the changed speed. It is an innovative engineering solution to arrest falls by two-disc anti-ratchet braking system.falarressystem is a personafalprotectiosystethaarrests a frefalanwhich limitthimpactforce on thbody of the user or goods during fall arrest.



In the event of a fall, the retractor will lock and suspend the person until either self-rescue or outside assistance becomes available.



                                                    Fall Arrester



Model

Maxi Load (Kg)

A

B

C

Cable Length (mm)

Cable Diameter (mm)

Weight (Kg)

GJ5

150

250

170

70

5

4

3

GJ7

150

260

175

80

7

4

4

GJ10

150

290

200

90

          10

4

6

GJ15

150

320

225

95

15

4

8

GJ20

150

420

300

100

20

4

13

GJ25

150

420

300

100

25

4

14

GJ30

150

370

110

30

30

4

18

GJ35

150

370

110

35

35

4

19

GJ40

150

370

110

40

40

4

20









Service Life

 _03_

 Although cable retractors are designed to provide years of trouble free service the type of atmosphere they are used in, or prolonged cable exposure to the sun or moisture may impact the overall service life. For example, use near chemical or paint sprays or failure to allow cable to retract when not in use will reduce the cable's life.



Immediately remove the cable retractor from service and discard if it has been used to arrest a free fall.



Immediately remove the retractor from service and inspection if the device has failed a visual inspection for any reason.



Always store in a cool dry place, always from chemical, water, direct sun light and sources of heat and vibration.



Always ensure cable section is completely retracted before storage.



It is especially important when retractors are left in place outside as components of a permanent fall protection system.
