polypropylene honeycomb core fiberglass honeycomb core (520567021)

Share on:


Price:RUB 554.77 - RUB 1,981.30
Price in USD:Details

Quantity:


Product Overview

Description



PP honeycomb panel (plastic PP sandwich panel)(building material)

Specifications :

             PP6   (Cellcore diameter is 6mm)*

PP8   (Cellcore diameter is 8mm)*

             PP10   (Cellcore diameter is 10mm)*

             PP12   (Cellcore diameter is 12mm)*

PP honeycomb panel can be supplied with both sides laminated with non-woven polyester tissue in either 40g/ m² or 60g/m², then clients can combine honeycomb with different panels easily .



pp honeycomb core is an excellent material for sandwich construction.

Its polyester non-woven surface is easy to be bonded and fit for most kinds of surface sheet.



Resin forced PP honeycomb panel can cut down body weight, increase speed, save energy widely used in boat, yacht, port, truck body etc.



PP honeycomb sandwich core has a polyester tissue laying resin and get a better bonding fast and easily.



Now we can provide cell sizes of 6mm/8mm/10mm/12mm.



T40, that is, tissue is 40g/square meter , T40 can prohibit as little as epoxy resin or glue leaking into cellcore.



T40F, that is, tissue is 40g/square meter with PP film , which makes honeycomb combined with tissue so tightly that it can save more glue when it is processed for FRP sandwich honeycomb structures.



T60, that is, tissue is 60g/square meter , T60 can prohibit as little as epoxy resin or glue leaking into cellcore so client can save resin.



T60F means tissue is 60g/square meter with PP film ,T60F makes honeycomb combined with tissue so tightly that honeycomb with T60F can be put into application without other panels.



Light weight, high compressive strength, anti-water, anti-humidity honeycomb can be used as structures in floor, ceiling, wall. Besides, PP honeycomb can cut down body weight, increase speed, save energy when honeycomb structures make guarantee for body strength, reinforce our PP honeycomb widely used in boat, yacht, port, bridge, truck body , and FRP sandwich honeycomb producing etc.



Max. length is 3100mm and we welcome friends from all over the world inquiry our plastic honeycomb.



Packaging & Shipping




PC honeycomb holds following characteristics, and brings widely application in different projects and fields.



PC honeycomb has many different kinds, and clients can choose from the excellent properties :

1.Cellcore uniformity, inside smoothness, cleanness, surface level off;

2.PC being safe for using as airflow in showcase;

3.Lower shrink rate when temperature drop to -30 degree.



 PC honeycomb can be applied in the window to save energy consumption, and the window installed with transparent PC honeycomb can lessen heat loss up to 80% than common windows;



PC honeycomb can be directly applied in the farm glasshouse;



PC honeycomb can also be applied in the solar heating, warming and drying.



Built-in Collecting and storing solar energy heaters with PC honeycomb run in low or high sunshine efficiency is better than vacuum heater. Solar heater with PC honeycomb run stable in winter and price is cheaper than vacuum heater, easy to match to building roof.



The honeycomb exhibits a unique cell structure. The core has 3 orientations vs. the 2 orientations common with other honeycomb, making its properties more uniform. Each cell has a tubular form and is inherently stable.



PC honeycomb is specially three dimensional structure, so it's more steady and equilibrium than other two dimensional honeycomb structure. PC honeycomb core stand by tightly to provide excellent compressive strength, besides PC honeycomb holds following characteristics, so that bring widely application in different project and fields.

-- Lightweight stiffness strength

-- Insulated

-- Fire resistant

-- Corrosion resistant

-- Fungi resistant

-- Energy absorption

-- Excellent dielectric properties

-- Good thermal and electric insulator

-- temperature -40 + 110 Celsius degree

-- Available transparent and in colors



PC Semi-manufactured products:

PC honeycomb, Max sheet length *Max sheet width is 3.0x1.5, meters, and normal size is 2.44*1.22m, thickness of 6mm ~ 300mm, Other size panels can also be taken into account according to your request. *



Features

Light Weight

High strength to Weight Ratio

Stiffness

Moisture ,Chemical, Corrosion, Smoke , and Fire Fungi Resistant

Conductive grades available*

Thermo-formable

Recyclable and Environment-Friendly

No Pollution



Availability:

Available cellcore diameter: 3mm---8mm

Common dimension: 1220x2400mm

Thickness: 2mm---400mm   Tolerance:+/-0.5mm

Specific dimension, cellcore , color, tolerance, shape can be made according to clients’ request.
