Product Overview

Description

Introduction

New type carbonization oven is our new invention.The inner pot can be hanged outside which saves the cooling time , so the productivity increases a lot.It is the ideal choice for mass procuction.This type of furnace adopts the structure of unique air storage chamber, to fully reuse the smoke produced during the process of carbonization.Sixty percent of the redundant smoke can be used in drying and carbonization which saves energy and increases the enterprise revenue.



Advantage:

1.Save cooling time

Adopt hoist type cooling structure; reduce the cooling time and production circle

2. Save production circle

One set carbonized stove can have 2 pieces inner pot, so that recycle using.

3.Save energy

It can reuse the smoke produced during the process of carbonization. 60% smoke can be used in drying and carbonized.

Feature

1.Short cycle time:the inner pot hanged outside so saves the cooling .

2.Big productivity:2 tons per day.

3.Less emission of smoke:the airstorage chamber adopted,60%of the smoke can be used in the process of carbonizing and drying.



Technical parameter



Model

DZ-260

DZ-500

DZ-1000

Capacity of raw material

570kg

1250kg

2500kg

Final production of charcoal

260kg

500kg

1000kg

Time of carbonization

6-8h

6-8h

10-12h

Time of cooling

10h

12h

20h

Total time

16-18h

18-20h

28-30h

Weight (including the inner port)

2.2t

2.8t

3.5t

Dimension

1.55*1.55*2m

1.9*1.9*2.0m

2.2*2.2*2.2m



The charcoal after carbonized:



Carbonization oven





Welcome to the Sanjin charcoal machinery factory, we will provide the best service for you
