Product Overview

Description

Product Description

 Grinding Machine,  HGM125 grinding mill

1. Grinding machine for mining, ore, chemical and construction, etc.

2. High fineness. Ultrafine grinding 325-2500mesh(47-5um) adjusted.

3. High capacity. 0.5-25 t/h. high efficiency.

4.  Long lifecycle of spare parts The ring and roller are forged by special material with high utilization.

5. High safety and reliability. As no rolling bearings or screws in grinding cavity, there are no problem caused by bolts shedding or rapid wear of bearings and seal components.

6. Environment-friendly. Application of pulse bag filter & muffler greatly alleviates dust pollution and  noise.

7.  Advanced intelligent speed control device. Convenient adjusting, uniform particle size.

Working Principle of Grinding Machine,   HGM125 grinding mill

37

After crushed by hammer crusher, the large materials become small ones and are sent to storage hopper by elevator, and then evenly sent to the upper distribution plate of the turn plate by vibrating feeder and sloping feeding pipe.



When the grinding mill is at work, the main bearing and each dial are driven by electromotor through reducer, and all the grinding rollers are rolling in the ring channels driving by dial through plunger. The materials are driven to the edge of the turn plate by the centrifugal force and fall down into the grinding chambers.



The high-pressure air blower constantly inhales air, the airflow with crushed materials are brought to the classifier whose high-speed impeller will screen the airflow: the unqualified particle size will fall and return to the mill for being reground while the qualified particle size mixed with air will go into the cyclone powder collector. Most of the qualified powders will fall and exit from the discharging valve at the bottom; a small proportion of the fine powders, with airflow, moves to the dust cleaner. The materials from the above two lots are sent by the conveyor to get finished powders packed. In addition, filtered clean air will be emitted from muffler in the end.



Main Unit&wearing parts of Grinding Machine,  HGM125 grinding mill

QQ20130118152652



Advantages of Grinding Machine,  HGM125 grinding mill

1. Ultrafine grinding 325-2500mesh(47-5um)

2. Fast delivery(20~30 days after deposit)

3.   The grinding material moisture under 5%.

4.   High capacity, 0.5-12 t/h.

5.   Reliable and durable, long lifecycle of spare parts.

6. Firm, durable(steady use for more than 30 years) & easy to use

7. Suitable for types of ores

8. Various of types/colors/size/specifications for selection

9. Hot sold by manufacturer/support OEM and ODM with good quality & price

10. Customer first, integrity highest

11. the only manufacturer in Shanghai



Main technical parameters of  HGM125 grinding mill

Model

HGM80

HGM90

HGM100

HGM100A

HGM125



Ring Diameter(mm)

800

930

1035

1035

1300



Ring Number(layer)

3

3-4

3

4

4



Roller Number (piece)

21

24-32

27

34-36

40-44



Main Shaft Speed (r.p.m.)

230-240

200-220

180-200

180-200

135-155



Input Size(mm)

≤20



Finished Size (μm/mesh)

5-47

(325-2500)



Capacity (t/h)

0.5-4.5

0.6-6.5

0.7-7

0.8 -8.5

0.9-12



Overall Dimension

(L*W*H, m)

13.9x4x6.2

14.7x4.8x7.2

18x4.6x8.6

18x4.6x8.6

14x9x10.25

Motor Power(KW)

145-165

175-192

263

263

378-408









Unit:KW

HGM80

HGM90

HGM

100

HGM

100A

HGM125



Main unit

55

2-37

110

160



Classifier

18.5

22

37

45



Blower

45

55

75

2-55



Crusher

11

11/18.5

18.5

18.5



Bucket elevator

3

3

3

4



Spiral Conveyor

3

3

3

2-4



Discharging valve

2-0.75

2-0.75

3-0.75

4-0.75



Air compressor

7.5

15

15

2-15



Company Information

Company Brief Introduction

SHANGHAI CLIRIK MACHINERY CO., LTD located in PUDONG New district of Shanghai china, as a pioneer enterprise, which is specializing in research, manufacture and sales of all kinds of grinding mill, from coarse grinding mill, fine grinding mill and ultra fine grinding mill, grinding mill related equipment, such as powder modifying machine, powder packing machine.powder conveying system, etc. We have devoted into grinding field for more than 30 years, we belive only focus can be professional



Our company has already formed a full set of modern production line, equipped with intelligent, standardized testing and controlling laboratories, owned a professional team for R&D, production, sales and service.





Our factory of HGM125 grinding mill

QQ20140809104540



Packing and Delivery of  HGM125 grinding mill

IMG_7514_



Customer Visit of  HGM125 grinding mill

QQ20140809104819



Our Certificates of HGM125 grinding mill

Our company has get ISO9001, our products have recieved CE certification and other qualifications.

QQ20140809104342



Our Services

 Our pre-sales service of HGM125 grinding mill

QQ20140809104312



Our after-sales service of  HGM125 grinding mill

(9M{9O~PT$WS7P$[A`_TXA

Welcome to Clirik !

Any needs and technical problems, contact us freely. We are more than glad to help. Our engineer will design a best solution drawing for you !
