Product Description



Overview of small diesel engine jaw crusher



1). Automatic secondary powder small diesel engine jaw crusher is composed of bracket; jaw; eccentric shaft; jaw plate;spring, etc.


2). Automatic secondary powder small jaw crusher is widely applied to crush high hardness, mid hardness and soft rocks and ores such as quartz,granite,limestone,slags, construction materials, marble,etc.
3). The maximum compression strength of materials to be crushed is 320MPA
4). PE series is used for primary crushing, and PEX series is used for secondary crushing and fine crushing

.

The preformance of product

1. Deep broken cavity, no dead zone, increased capacity and output;
2. Large crushing ratio, uniform particle size products;
3. style nesting population adjustment devices, and ease of adjustment range, and increase the flexibility of the equipment;
4. Safe and reliable lubrication system, convenient replacement parts, small maintenance workload;
5. Structure is simple, reliable; low operating costs for small portable stone crushers .
6. Energy-saving equipment: stand-alone energy-saving 15% ~ 30%; energy saving of the system is more than doubled;

7. The discharging size of jaw crusher can be adjusted to meet the requirements of different users;

8. Low noise and less dust

2 029.jpg



















































Working principles of small diesel engine jaw crusher

 1).This crusher adopts the electric motor as the power.

2).The eccentric shaft is revolved by an electric motor through v-belts.

3).It makes the swing jaw to follow the preconcerted path to crush the material.

4).The crushing chamber is composed of the stationary jaw plate, swing jaw plate and the liner plate.

5).The material is discharged from the lower part of machine.



Product dates



ModelFeed opening
size
(mm)
Max
feed
size(mm)
Adjustable
range
(mm)
Capacity
(t/h)
Eccentric shaft
rotary speed
(r/min)
Motor
power
(kw)
Total weight
(t)
Overall dimensions
(L*W*H)(mm)
PE-150×250150×25012510-401-32505.50.8720×660×850
PE-200×300200×30018015-502-62607.51.2910×750×990
PE-200×350200×35018018-703-10260111.51000×870×990
PE-250×400250×40021020-605-20300152.81300×1090×1270
PE-400×600400×60034040-10016-602753071730×1730×1630
PE-500×750500×75042550-10040-11027555121980×2080×1870
PE-600×750600×750500150-20080-2402755515.82070×2000×1920
PE-600×900600×90050065-16050-18025055172190×2206×2300
PE-750×1060750×106063080-140110-32025090-110292660×2430×2800
PE-800×1060800×1060640160-220130-33025011029.82710×2430×2800
PE-830×1060830×1060650160-220150-33625011030.72740×2430×2800
PE-870×1060870×1060660200-260190-33625011031.52810×2430×2800
PE-900×1060900×1060685230-290230-390250110332870×2420×2940
PE-900×1200900×120075095-165220-450200110523380×2870×3330
PE-1000×12001000×1200850195-265315-500200110553480×2876×3330
PE-1200×15001200×15001020150-300400-800180160100.94200×3300×3500
PEX-150×750150×75012018-488-25320153.81200×1530×1060
PEX-250×750250×75021025-6013-35330305.51380×1750×1540
PEX-250×1000250×100021025-6016-523303071560×1950×1390
PEX-250×1200250×120021025-6020-61330379.72140×1660×1500
PEX-300×1300300×130025020-9016-1053005515.62720×1950×1600

IMG_7313IMG_8757IMG_4165IMG_6257IMG_4160

 mobile jaw crusher station picture display

IMG_2494IMG_0269356($MVM)5}DQ$C%T7ONNHQIMG_1035

We also have large type jaw crusher, if you want to know more, please contact me!we offer to visit our factory
