Solid and liquid measurement 4-20mA or 4 lead wires Radar level transmitter

Product Description.jpg



FMCW radar adopts a high frequency signal, which is emitted via an antenna and swipe frequency increment by 0.5GHz during the measurement, reflected by the target surface and received at a time delay. The frequency difference,  which is calculated from the transmitting frequency and the received frequency, which is directly proportional to the measured distance (or material surface).

The frequency difference then is processed by Fast Fourier Transformation (FFT) to identify the signal in Intermedium Frequency (IF).  This FMCW radar is innate with signal / noise enhancement and filtering of echo-back via Phase-Lock Loop (PLL) circuit that is the best solution for complex environment and high accuracy measurement.




  • Non contact measuring
  • Corrosive and toxic liquid, hydrocarbons, slurries
  • Not affected by specific gravity, pressure, temperature, viscosity, foam, and dust
  • 5 digits LCM display
  • Indicate signal wave inside the silo.
  • Selection of Different Measurement unit(m, cm, mm, inch, ft, %, mA)
  • Measuring distance and actual level.
  • Language selection of traditional Chinese, simplified Chinese, English.
  • 4-20mA/ 4 lead wires
  • Modbus RS-485 to enhance isolation and easy for remote control.
  • CE standards for isolation(EFT 2000V, B class or better)
  • Suitable for mid-range signal
  • 4-20mA output
  • Set functions to the continuous measuring device via FAS software.
  • Isolated circuit design.
  • High voltage : IEC60947-2
  • Isolated resistance : IEC60092-504
  • Power supply change : IEC60092-504
  • Power supply failure : IEC60092-504
  • Electrical burst testing : IEC61000-4-4
  • Voltage DIPS : IEC61000-4-11
  • Humidity : IEC60068-2-30
  • High/Low temperature test : IEC60068-2-38
  • IP protection rating : IEC60529
