XiangStar SXOJ30 Series/Closed Mechanical CNC Turret punch machine/Multi stations

Working Principle

Closed mechanical cnc turret punching machine by the programming software (or manual) processing program, by the servo feeding mechanism sent the plate material to the required processing position, at the same time by the die selection system select the appropriate die from the turret, by the mechanical power system according to the procedure of punching, automatic completion of the work piece processing.

Technical Parameter

Name

Parameters

Unit

Remark

Nominal Pressure

300

KN

30 (T)

Rack Structure

O



Closed type

Turret Structure

Thick

mm

80(up)/70(down)

Mold Structure

85 series

Long oriented

Internationally general type

Clamp Structure/Number

3

Sets

Full floating type

Controlled Axis Number

3



X/Y/T

Repositioning Cylinder

2

Sets



Countertop Structure

Mixed



Brush / Universal ball

Turret station distribution

A/B/C/D

Sets

A:7;B:12; C:4; D:2

Punching Accuracy

+-0.1

mm



Repeat Positioning Accuracy

+-0.02

mm



Throat Depth

1280

mm



Punch Stroke

40

mm



Max. Punching Frequency

270

Times/min

180/270 (dual speed)

Max. Punching Plate Size

5000*1250

mm

Repeat Positioning

Max. Punching Plate Thickness

5

mm



Max. Plate Feeding Speed

80

m/min



Max. Diameter

88.9

mm

Once punched

Max. Work piece Weight

150

kg



Turret Rotary Speed

30

r. p.m



Main Motor Power

5.5

KW



Power

13.8

KVA

AC/3PH/380V

Gas Source

0.6/0.15

Mpa



Dimension (L*W*H)

4600*5000*2200

mm



Weight

10

Ton

Near

CNC System





SIEMENS 808D

Software





CNCKAD

Product Features

Application

Packaging & Shipping

Company Information

Qingdao Xiang Star CNC Machinery Co., Ltd., is a high tech enterprise integral of the ability of R&D; Production; Sales.

Covers an area of 50 acres and plant area of 10,000 square meters; we located in No. 789, Guangda Road; Huangdao District; Qingdao City; Shandong Province; China.

As an original state owned restructured enterprise, we have more than 12 years experience in manufacturing and service in sheet metal processing industrial.

Especially in the field of manufacturing CNC (turret) punching machine and fiber laser cutting machine, we have deep technology accumulations.

Such as “Haier” ;“Sunrain”; “Midea” these big and influential companies are our company’s long term cooperative customers. Most of our customers are come from old customers or customers introductions.
