4 Channel network car video surveillance system

Share on:

Price:RUB 18,593.09 - RUB 34,506.82
Price in USD:Details


Add to Cart
  • add to wishlist

Product Overview


4 Channel network car video surveillance system

VM4004-NVR ,HIS Solution,H.264 Compression,support 4CH Networking 1080P or 4CH networking 720P HD surveillance video recording and play back.

Main Features:

1.2CH video output (1CH CVBS video output, 1CH VGA output )

2.Exclusive pre-allocate File System protect data completeness,prevent SD Card fragment

ensure date stablyand completely.

3. 8-38V wide voltage with low power consumption.Support Reverse Protection, over-voltage/over-current

protection.support 12V & 5V peripheral equipment power supply. Ultra low power design; Unique UPS

Technology ensures the integrity of record when power failure occurs,even can for 8-10s.

4.HDD+SD Card Storage ( Support 2.5” HDD, max 128G SD Card)

5.Support 2 USB ports for backup data and DVR upgrading;

6.Support 10CH alarm input (2CH analog input + 8CH IO alarm input ),2CH independent alarm output.

7.Support 2 CAN interface Support HDD heating functions,can work in cold environment.

8.Support GPS/BD/G-Sensor Extension module;

9.Realize real-time monitor through 3G/4G; Support SMS remote configuration/control DVR; Support

Broadcast/Intercom/Text sent etc;can add oil sensor/temperature

10. Support GPS/BD,3G/4G Module Optional,WIFI extend

car video surveillance systemcar video surveillance systemcar video surveillance systemcar video surveillance system


car video surveillance system

LanguageChinese/English/Others (can be customized)
Video CompressionH.264 Compression Mode
OSDOverlays information such as date time and vehicle ID
GUIGraphical User InterfaceSetup system parameters with the remote control.
Video Record SystemVideo Input4CH 720P AHD input/4CH SD input/2CH HD + 2CH SD mixed input , aviation connector, 1.0Vp-p, 75Ω
Video Output1 CVBS + VGA output for optional , 1.0Vp-p, 75Ω,Aviation,Support 1CH Full Screen,4CH Screens
PreviewSupport 1 channel and 4 channels preview, Support Manual/Alarm Trigger full screen preview
Resolution720P/D1/HD1/CIF, MAX:4 channels 720P
Video Quality0-7 levels, 0 is the highest level, 7 is the lowest level.
Video StandardP/N/CIF/HD1/D1/720P
Record ModeThe default setting is auto recording after power on. Timed recording, alarm trigger recording and manual recording are supported.
AudioAudio Input4CH ,Aviation Plug
Audio Output1CH,Aviation Plug,The output level: 1V - 2V
Alarm Input4Ch Alarm Input
Alarm Output1CH Relay Alarm Output
Communication Interface1CH RS232 or 1CH RS485
Wireless transferSupport Built-in 3G/4G network, WCDMA,CDMA2000,TDD-LTE,FDD-LTE...
Support Built-in/External WIFI,Compatible with GPRS,EDGE
PositionSupport Built GPS/BD Module, can make playback analysis of vehicle routing
G-SensorSupport G-sensor
Voltage & Power ConsumptionVoltage InputDC:+8V ~ +36V
Voltage Output+12V/2.5A,+5V/2.5A
Power-off ProtectionUPS Technology,All video information can be saved automatically when the power is cut off, and make sure that all the files can not be damaged.
Power ConsumptionNormal Working <14W Stand-by Status <0.5W
User interface

The client software :CMS/RMS

Interface on comoputer

car video surveillance systemcar video surveillance systemcar video surveillance system

Packaging & Shipping

car video surveillance system

car video surveillance system


Product process

car video surveillance systemcar video surveillance system

our company

Visionmaster Industrial Co., Ltd. is a leading video surveillance solution provider with global perspective. Before we got this new company name(Visionmaster), we have been in the field for 8years. Our team has been steadily growing from the initial 3 founders up to more than 100 employees. Through our dedication to customer-centric innovation and strong partnerships, we are creating maximum value for international distributors, installers by committing end user competitive mobile surveillance and DVR solutions. Our solutions have been deployed worldwide among various applications including public transportation, school bus, law enforcement, private fleet, logistics management, railway and metro, mobile media operation, etc. We continue to enjoy rapid and steady growth and would like to invite you to be part of our global success.
