Portable TIG200A DC Inverter TIG welder

Share on:


Price:RUB 5,913.81 - RUB 9,098.16
Price in USD:Details

Quantity:

  • add to wishlist

Product Overview

Description

Product Description

Portable TIG200A DC Inverter TIG welder

1) Two functions of TIG/MMA welding, economic and pratical

2) High frequency arc striking, strong welding permeability

3) Easy for arc striking, the MMA welding can be applicable to many kinds of rods, convenient and pratical

4) Led digital show

5)Widely use in various metals such as stainless steel, alloy steel, copper, mild steel and other metals

ITEM/MODEL
TIG160A
TIG180A
TIG200A
TIG250A
TIG300A
Input power
voltage/Frequency(V/HZ)
Single phase
220±15% 50/60
Single phase
220±15% 50/60
Single phase
220±15% 50/60
Single phase
220±15% 50/60
Three Phase 380±10% 50/60
Rated input power capacity( KVA)
4.4
4
4.6
6.4
8.4
Output current range (A)
10-160A
10-180
10-200
10-250
10-300A
Rate output voltage(V)
16.4
17.2
18
20
22
No-load voltage(V)
56
56
54
54
58
Duty cycle (%) (25℃)
60
60
60
60
60
Efficiency (%)
85
85
85
85
85
Power factor (COSφ)
0.93
0.93
0.93
0.93
0.93
Weight (KG)
8
8
8
18
19
Overall dimension (mm)
371*153*299mm
371*153*299mm
371*153*299mm
480*203*355
480*203*355
Insulation class
F
F
F
F
F
Protection class
IP23
IP23
IP23
IP23
IP23
Post-flow time(S)
5
5
5
5
5
Welding thickness
0.3-6
0.3-8
0.5-10
1.0.5-10
0.5-12

Standard ACC for Portable TIG200A DC Inverter TIG welder


4M cable tig torch

3M cable with electrode holder

3M cable with earth clamp clamp

3M,220V input power cable

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

* one year warranty, will send free spare parts for repairing.

Packing & Delivery

for Portable TIG200A DC Inverter TIG welder

Packaging
Size
450 (L) * 345 (W) * 270 (D)
Weight
10KG



Packaging Details
The normal package is carton box(Size: L*W*H). If possible, will be packed with pallet. it will be protected well. If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Packaging
Size
20GP: 670PCS
40GP:1350PCS
Weight
10KG



Shipping Details
The normal package is wooden box(Size: L*W*H). If export to european countries,the wooden box will be fumigated.If container is too tigher,we will use pe film for packing or pack it according to customers special request.
