Product Overview

Description

Outrunner BLDC motor 20080 48v brushless dc motor 50KV 45KW Paramotor drone motor





1.Product Feature.jpg



LIGHTWEIGHT AND INCREDIBLY POWERFUL: 40000-50000W POWER
This motor is a monster! Built with what exists latest in brushless power technology, it has been specially designed and developed to use on powerful electric paramotors and other electric prototypes full scale. Lightweight, compact and silent. Unquestionably, the most modern big outrunner brushless motor available at the moment.



Lightweight, compact and silent
Super modern design with aluminum heatsink case
Ball Bearing NSK Japan
Real high quality, efficiency and performance
Ultra high torque motor with lower KV: 85Nm maximum continual
Thrust up to 90Kg on max. voltage and amperage
Recommended for the most audacious prototypes electric paramotors
Use it also in small eletric prototype veichles, airplanes, go karts, big drones, etc
Also available ''watercooled'' version (Optional with extra charge)








Model Number: RT20080
Max. Power (power peak): 40-45KW
Cont. Power: 25KW
KV: 28KV, 50KV, 80KV optional
No load current (20v testing voltage on 28KV): 2A
Resistance: 0.036ohm
Stator/magnet: 36/40
Shaft: 20mm hollow shaft
Size (diameter*height): 202mm x 80mm (without shaft)
Weight (aprox): 6.4Kg or 14.2Lbs

SHAFT: 20mm hollow shaft

Accessory Bag: included

Thurst: 90kg

Torque: 85Nm maximum continual











20040 (3).jpg20040 (1).jpg20040 (4).jpg





20040 (6).jpg



Motor Packing.jpg5.Our Certificate.jpg6.factory.jpg7. .jpg8.Our Company.jpg9.Shipping Advice (2).jpg10..jpg
