high quality GR2 Titanium Exhaust pipe Dia=38mm/50.8mm/63.5mm/76mm/89mm tube motorcycle Auto exhaust pipe

Product Description


Material: pure Titanium (Gr2)

Tubing Size:1.5"(38.1mm)/2.0"(50.8mm)/2.5"(63.5mm) 3" (76.2mm)/3.5"(88.9mm)/4.0"(101.6mm) etc
Tubing Length: 39.4 Inches (1.0 Meters)
Wall Thickness: 1mm / .039" /1.2mm
Style: Seamless/welding
Surface: pickling surface/polish surface etc


1.Titanium straight tubing stock

Seamless (SMLS)

OD 38 X WT  1.0mm x L 1000mm

OD 45 X WT 1.0mm x L 1000mm / OD 45 X WT 1.2mm x L 1000mm

OD 51 X WT 1.0mm x L 1000mm

OD 60 X WT 1.0mm x L 1000mm

OD 63 X WT 1.0mm x L 1000mm/ OD 63 X WT 1.2mm x L 1000mm/ OD 63 X1.5 XL 1000mm

OD 70 X WT 1.0mm x L 1000mm

OD 76 X WT 1.0mm x L 1000mm/OD 76 X WT 1.2mm x L 1000mm/OD76 X WT1.5mm

OD 80 X WT 1.0mm x L 1000mm

OD 89 X WT 1.3mm x L 1000mm



Welded

OD 101.6 X WT 1.0 X L 1000mm/OD 101.6 X WT 1.2 X L 1000mm

OD 127.0 X WT 1.0 X L 1000mm

OD 152.4 X WT 1.0 X L 1000mm etc.



2. Suit product

1)Titanium welding rod , Dia 0.8/1.0/1.2/1.5/1.6mm x L 1000mm

2)V- band clamp  (2pcs titanium gr2 flange + 1pc ss304 clamp)

3) elbow or bends ,   45 / 90 degree  38/45/51/60/63/76/89mm in stock

4) 2 bolts exhaust flange, 1.5"/2.0"/2.5"/2.75"/3.0"/3.5" etc

5) Pie cuts,   9 degree, tight and loose radius,

6)perforated pipe,   1.5"/2.0"/2.5"/2.75"/3.0"/3.5" etc ,  2.0mm holes, staggered line and straight line;

7) titanium hanger rod,   Dia 10/12/15mm x L 1000mm

8)reducer,  3" to 2"/ 3" to 2.5/ 2.5" to 2"/ 3.5" to 3.0"/3.5" to 2.5"

9)muffler,  2.5" inlet and outlet;  3.0 inlet and outlet; 3.5 inlet and outlet etc



Mechanical Properties(>%)

Grade Tensile Strength(min) Yeild Strength(0.2% offset)) Elongation(%)
ksi MPa  Min Max
Ksi Mpa Ksi Mpa
1 35 240 25 170 45 310 24
2 50 345 40 275 65 450 20
7 50 345 40 275 65 450 20
9 90 620 70 483 - - 15C
12 70 483 50 345 - - 18C
