IPC-9800ADHS PLUS 7 inch CCTV security camera tester for TVI CVI AHD SDI IP Analog testing

Share on:

Price:RUB 15,498.01 - RUB 38,939.70
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Model IPC-9800ADHS PLUS

7inch CCTV  security camera  Tester Touch Screen Monitor Onvif AHD/TVI/CVI HDMI 1080P/PTZ/POE/WIFI/FTP Server/IP Scan Tester



Basic model : IPC-9800 Plus

 Optional functions below  :IPC-9800Plus+CLMOVTADHS or ADHS or ADH

1)CLMOVTADHS : TVI +CVI+AHD+SDI/EX SDI+digital multimeter+optical power  2)meter +visual fault locator+ TDR cable test+cable tracer+ video level meter

2)  ADH :TVI +CVI+AHD

3)ADHS:TVI +CVI+AHD+SDI/EX SDI





Features



1.     New -7 inch IPS touch screen,1280*800 resolution

2.     New- H.264 and H .265 ,4K video display via mainstream

3.   New- 8MP TVI test,video record and playback ,coaxial PTZ control and call camera OSD menu

4.   8MP AHD test, ,video record and playback ,coaxial PTZ control and call camera OSD menu

5.  8MP CVI test, 4xzoom ,video record and playback ,coaxial PTZ control and call camera OSD menu

6.     IP & CVBS camera test, PTZ controller

7.     New- Rapid video, just by one key to detect all network cameras and auto display

8.     Rapid ONVIF, auto log in and display image from the camera, activate IP camera, and also can create testing report

9.     New- IP and analog testing at the same time , converter test from analog to digital with dual test window IP & CVBS

10.   New- Screen management, change function’s icons order, create new directory

11.   New- Shortcut button, drop-down menu , can select PoE power ,IP setting, WLAN switch, HDMI IN functions etc in any interface

12.   Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, can save testing report, if special number, need customized

13.   New- RJ45 cable TDR test, test cable pair status, length, attenuation, reflectivity, impedance, skew etc

14.   TesterPlay(screen projection): tester, android version mobile phone and PC display at the same time

15.   New- Screen lock, password lock and pattern lock are optional

16.   New- HDMI signal input,720×480p /720×576p /1280×720p /1920×1080p /1024×768p/1280×1024p /1280×900p /1440×900p display image ,record and snapshot

17.   HDMI output ,support 1080P

18.   New- CVBS loop test , the tester send and receive color bar generator signal ,to check BNC cable

19.   New- Traffic monitoring of the tester "LAN port", display network port or WIFI connection real-time upload and download speeds and other network parameters

20.   New- Customers self update software ,you can install apps with android version ,such as Skype, wechat etc

21.   ONVIF camera test, support 2592*1520, Network PTZ controller (ONVIF)

22.   Built in Wi-Fi ,display image from the wireless camera , create WIFI hotspot

23.   New- 4K video files and MKV/MP4 media files play

24.   PoE DC48V power output, Max power 24W,12V /2A power output/5V 2A power output, as a power bank

25.   New- Quick office, quick office app ( support excel ,word ,ppt format ) doc. editable

27.   IP discovery, it can auto-scan the whole network segment IP, and auto-modify tester’s IP address

28.   Enhanced Color bar generator, PAL/NTSC multi-system color bar video generator

31.   POE voltage measurement, PING test ,IP address scan, port flashing etc

32.   7.4 V /7500mAh Lithium Ion Polymer Battery, fast charging 3.5 hours working time lasts 16 hours



Packing kits :

                 1). Tester

                 2). Adaptor DC12V 2A

                 3) Network cable tester

                 4) Polymer lithium ion battery (7.4V DC 7500mAh)

                  5). BNC cable

                  6). RS485 cable

                  7). SC,ST connector(Only for optical power meter)

                   8). Multi-meter test leads one pair of red and black (only for the Multi-meter models)

                  9). Output Power cable

                  10). Audio cable

                  11). TDR alligator clamp (only for TDR models)

                  12). Safety cord

                   13). Tool bag

                   14). Manual

                   15).8GB SD card
