RC Soft High Temperature Silicone Wire 6AWG 8AWG 10AWG 12 14 16 18 20 22 AWG Cable Red Black color For Lipo Battery ESC Servo

Share on:


Price:RUB 0.7872 - RUB 236.14
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description



Product Description

"Quality first, customer first" is our development policy, to provide customers with one-stop product supply program, and constantly improve our products and service system is the mission of the company.

Specification table:



Specifications

   (AWG)

Copper wire shares

(compos.NO./mm)

Insulation thickness

 (mm)



Diameter (mm)

Overall diameter

(mm)

Conductor resistance

(Ohm/km)

Sectional area      (mm2)

Carrying current

(ampere)

packing

(M/coils)

6AWG 3200/0.08mm 1.65 5.2 8.5 1.21 16.08 300 100
8AWG 1650/0.08mm 1.2 4.4 6.3 4.1 8.29 190 100
10AWG 1050/0.08mm 5.28 2.92 5.5 6.3 5.3 140 100
12AWG 680/0.08mm 3.42 2.41 4.5 9.8 3.4 88.4 100
14AWG 400/0.08mm 2 1.85 3.5 15.6 2.07 55.6 200
16AWG 252/0.08mm 1.3 1.47 3 24.4 1.27 35 200
18AWG 150/0.08mm 0.75 1.13 2.3 39.5 0.75 22 200
20AWG 100/0.08mm 0.5 0.92 1.8 62.5 0.5 13.87 400
22AWG 60/0.08mm 0.3 0.72 1.7 88.6 0.33 8.73 400
24AWG 40/0.08mm 0.2 0.58 1.6 97.6 0.2 5 400
26AWG 30/0.08mm 0.15 0.44 1.5 123 0.14 3.5 400
28AWG 16/0.08mm 0.08 0.32 1.2 227.2 0.08 1.25 100
30AWG 11/0.08mm 0.055 0.3 0.8 331 0.06 0.8 100



Description :

¤1) Special Soft Silicone wire : 16AWG
¤2) Wire diameter : 3mm
¤3) Conductor size : 16AWG
¤4) Conductor material : tinned copper
¤5) Insulator material : silicone Rubber
¤6)Rated Temperature : -60°C~+200°C
¤7) Single wire diameter : 0.08mm
¤8) Nominal Voltage : 600 V
¤9) Test Voltage : 2000 V
¤10) Colors : Black ; Red ; White ; Blue ; Yellow; Green;Orange


2AWG:Red Black

4AWG:Red Black

6AWG:Red Black Blue

8AWG:Red Black Blue White Yellow Green Orange

10AWG:Red Black Blue White Yellow Green Orange

12AWG:Red Black Blue White Yellow Green Orange

13AWG:Red Black Blue White Yellow Green Orange

14AWG:Red Black Blue White Yellow Green Orange

16-30AWG:Red Black Blue White Yellow Green Orange
