HORIZONTAL AXIS WIND TURBINE L TYPE
Rated power
1000W
Rated voltage
24V/48V
Wheel diameter
2.9m
Blade number
3pcs
Start wind speed
2.5m/s
Blade material
Reinforced glass fiber
Control system
Electromagnet
Working temperature
-40℃~80℃
Product Description

WIND TURBINE L TYPE FEATURES:

1.Casting aluminum alloy body, compact, little vibration;

2.Excellent output, 900w at 8m/s;

3.Easy installation,tube or flange connection optional;

4.Reinforced glass fiber blades, matched with optimized aerodynamic shape and structure, which enhance the wind energy utilization and annual output;

5.Tail adopts mechanical yaw technique, making it survive storm and run safely;

6.Patentd permanent magnet ac generator with special stator, effectively reduce torque, well match the wind wheel and generator, and ensure the performance of whole system;

7.Controller, inverter can be matched according to customers' specific needs.


Model
        LS-1000L
       LS-1500L
      LS-2000L
       LS-2500L
Rated power
1000W
         1500W
        2000W
       2500W
Maximum power
1200W
         1700W
         2300W
       2800W
Rated voltage
24V/48V
         48V/96V
      48V/96V
      48V/96V
Start up wind speed
2.5m/s
          2.5m/s
      2.5m/s
       2.5m/s
Rated wind speed
11m/s
         11m/s
       11m/s
       11m/s
Survival wind speed
45m/s
         45m/s
       45m/s
       45m/s
Top net weight
45kg
          50kg
         55kg
       60kg
Wheel diameter
2.9m
          3.2m
        3.7m
        4.7m
Blades number
                                                                3
Blades material
                                                        Nylon fiber
Generator
                            Three phase permanent magnet ac generator
Magnetic steel
                                                           NdFeB
Generator case
                                                Die-casting aluminum
Control system
                                                       Electromagnet
Speed regulation
                                              Automatically adjust windward
Working temperature
                                                        -40℃~80℃
Company Information
FAQ

Q1. Can I have a sample order for Wind turbine?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A:Sample needs 2-3 days, mass production time needs 1-2 weeks for order quantity more than

Q3. Do you have any MOQ limit for wind turbine order?

A: Low MOQ, 1pc for sample checking is available

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for wind turbine?

A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.

Q6. Is it OK to print my logo on wind turbine product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 1-3 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less
than 0.2%.
Secondly, during the guarantee period, we will send accessories with new order for small quantity. For
defective batch products, we will repair them and resend them to you or we can discuss the solution i
ncluding re-call according to real situation.
