China best price nail making machine for bangladesh and south africa and kenya

Share on:

Price:RUB 146,686.20 - RUB 366,715.50
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

China best price nail making machine for bangladesh and south africa and kenya

Product Description

 Description of wire nail making machine

 UNIWIN Nail making machine is designed for 1-6 inch nails, just feed the wire Q195/SEA1008/ SEA1006/Q235 low carbon steel wire into nail making machine, it will cut the steel wire into nails.



nail making machine  .jpg



Features of the wire nail making machine



z94-4C series is our new designed product with the advantages of :



1. Very low noise, the noise will not let people feel uncomfortable .



2. wire nail making machine main parts(Shaft, Cam, Gear) are made of high grade steel with professional heat treatment to ensure nails machine have longer working life and less time maintenance.



3. Auto lubrication: just add the lubricant into the small oil tank, then the machine can lubricate machine parts automatically.



4. Bearing structure and longer lifetime.



5. Each wire nail making machine will supply related spare parts of nail mould ,nail knife and punch pin, ect .





Technical Data

 Technical data of wire nail making machine



Model of Nail making machine

Z94-5C

Z94-4C

Z94-3C

Z94-2C

Z94-1C

Max. dia. of nail

5.5mm

4.5mm

3.1mm

2.8mm

1.6mm

Min. dia. of nail

3.8mm

2.8 mm

1.8 mm

1.2 mm

0.9 mm

Max. Length of nail

150mm

100mm

75mm

50mm

25mm

Min. length of nail

80mm

50 mm

30mm

16mm

9mm

Motor power

5.5kw

4kw

2.2kw

2.2kw

0.8kw

Nail making speed

220pcs/min

260pcs/min

320pcs/min

350pcs/min

450pcs/min

L*W*H

2.5*1.8*1.5m

2.2*1.6*1.65m

2.0*1.4*1.4m

1.9*1.356*1.4m

1.55*1.3*1.1m

Weight

2.2tons

2tons

1.5 tons

1 ton

750kg





Whole nails making Process of wire nail making machine



The whole process of nails production line: wire drawing --- nails making ---polish --- nails packing


1. Wire drawing machine -- to draw the 6.5mm/5.5mm wire diameter to the smaller wire size diameter to make nails as your required such as 4.1mm, 3.4mm, 3.1mm, 2.5mm etc. wire diameter
2.Automatic wire nail making machine --- feed the drawn wire into nail making machine to make nails.
3. Polishing machine -- to polish finished nails to remove the thron and dust and make nails more black and shiny.
4. wire nails Packaging--- pack the nails in cartons or plastic bags, or kraft bag in 5kg, 10kg, 15kg, 20kg, 25kg nails, etc.



nail production flow .jpg









Z94-4C series wire nail making machine :


The function of nail making machine is to make the nails into different size through adjust the nail making machine. It needs to put the suitable wire diameter into the entrance of the nail making machine, then start the nail making machine, it will finish nail making automatically.



nail making machine.jpg



  wire nail making machine structure detailed pictures



For our nail making machine, it is strengthened type, the frame is more heavy to ensure the fixedness of frame after tension. we pay more attention on every small parts details, all these small details ensure the best quality of the nail making machines so that it can run for many years without problem.



wire nails machine  (31).jpg



wire nails machine  (42).jpg



wire nails machine  (21).jpg



wire nails machine  (40).jpg











wire nail making machine Spare parts:



spare parts nail machine.jpg
