GEYA 2018 NEW Mini ATS Automatic Transfer Switch Electrical Selector Switches Dual Power Switch

Share on:

Price:RUB 1,973.44
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

GEYA 2018 NEW Mini ATS Automatic Transfer Switch Electrical Selector Switches Dual Power Switch

Banner


Product Description




General



W2R series dual power automatic transfer switch is new developed micro household power transfer switch.. The switch is mainly used for testing whether normal or spare power is normal or not. When the normal power is abnormal, the spare power works at once, which therefore ensures the continuirty, reliability, and safety of power supply. The product is specially designed for household orbit-type installation and specially use in PZ30 power distribution box.



W2R series automatic transfer switch is suitable for the emergency power supply system with 50 or 60 Hz alternatting current rated 400V 60A. TSE is compact in structure, reliable in transfer, convenient in instabllation and maintenance, and has long lif expectancy. Widely used In various occasions where continuous power failure ls not allowed, it can be operated both electrically and manually.



ATSE is composed of TSE and the controller. ATSE compiles with requirements of Low-voltage Switch Gear and Control Gear specified by GB/T14048. 11, Part 6-1 : Multiple functional equipment and transfer switch equipment.


Technical Data

ITEM NO.W2R
Rated current Ie(A)16A, 20A, 25A, 32A, 40A, 50A, 63A,100A
InstallationDin rail
Rated insulation voltage Ui (V)AC690, 50HZ
Rated working voltage Ue (V)AC400, 50HZ
Rated impulse withstand voltage (KV )8KV
Poles2P                3P                  4P
Weight (KG)1.7                2.1                 2.6
Connecting and breaking6.0Ie    1.05Ue      cosØ=0.50±0.05, 50 times
Operating performance2.0Ie    1.05Ue     cosØ=0.80±0.05, 6000 times
Rated limited short-circuit current Iq50KA
SCPD (FUSES )RT16-00-63A
Control circuit

Rated supply voltage Us: AC220V, 50HZ.

Working condition:85% Us~110% Us

Ancillary circuit

Two isolated relays, each relay with 2 groups of passive

switch contact. Contact capacity: AC220 50Hz, Ie=5A

Switching time<50ms
Action time<50ms




0.03 s.
