Product Overview

Description

4ch SD card GPS and 4g mdvr vehicle camera system

 product description:

VM-l404HD is a dual SD card hybrid HD MDVR with combined 4 channels of D1/960H/72oP audios video recording and replaying specially designed for vehicles, maximum 4 channels of 960H and 1 channel of IPC HD camera full-framed recording supported.



 4ch SD card GPS and 4g mdvr vehicle camera system

 Order Model:

Order ModelVM-1404N-HD
(2 SD cards)
VM-1404G-HD
(2 SD cards)
VM-1404GW-HD
(2 SD cards)
VM-1404GT-HD
(2 SD cards)
VM-1404GWT-HD
(2 SD cards)
VM-1404GF-HD
(2 SD cards)
VM-1404GWF-HD
(2 SD cards)
Description/GPSGPS
WIFI 5.8G
GPS
3G(WCDMA)
GPS
WIFI 5.8G
3G(WCDMA)
GPS
4G FDD
GPS
WIFI 5.8G
4G FDD





 parameter:



ItemParameterPerformance Indicator
SystemLanguageChinese/English
Operating interfaceGraphical user interface
Password & securityUser password and Admin password management
VideoVideo input4-channel air analog video input + 1-channel RJ45 network camera input
4 ways of D1/960H/720P composite video inputs available
Or 4 ways of composite video inputs + 1 way of IPC HD video input available
AudioAudio input4 audio inputs
Audio output2 audio outputs (one is φ3.5 Phone Jack, and the other is 24PIN connector)
Recording modeSynchronous video & audio recording
StorageTwo SD cards supported, 128 GB for each
AlarmAlarm inputEight alarm inputs. You can set the lower level alarm (1V or below) or upper level alarm (5V or above)
Alarm outputOne alarm output, the higher level of this output is up to 12V
Communication interfaceRS485 interfaceOne RS485 interface supported
RS232 interfaceTwo RS232 interfaces supported
Wireless3GBuilt-in 3G (HSDPA/EVDO/TD-CDMA) module (optional)
4GOptional built-in 4G communication module (FDD-LTE/TDD-LTE optional)
WIFIBuilt-in WiFi module
GPSWritable code stream such as built-in GPS module, GPS coordinate, GPS rate supported; in addition, wireless uploading is possible (optional)
Acceleration sensorExternal and built-in acceleration sensor G-Sensor (optional)
Supporting softwarePCplayback analysisPlay back video file in PC, and analyze vehicle information in the file
CMSThe centralized management software can realize preview, upload and center command issuance and parameter configuration
Software upgradeThis device can be upgraded through USB2.0 interface and remote CMS



















4ch SD card GPS and 4g mdvr vehicle camera system4ch SD card GPS and 4g mdvr vehicle camera system



Product production and packaging





4ch SD card GPS and 4g mdvr vehicle camera system4ch SD card GPS and 4g mdvr vehicle camera system4ch SD card GPS and 4g mdvr vehicle camera system4ch SD card GPS and 4g mdvr vehicle camera system

 Company information:

 Visionmaster Industrial Co., Ltd. is a leading video surveillance solution provider with global perspective.  Before we got this new company name(Visionmaster), we have been in the field for 8years. Our team has been steadily growing from the initial 3 founders up to more than 100 employees. Through our dedication to customer-centric innovation and strong partnerships, we are creating maximum value for international distributors, installers by committing end user competitive mobile surveillance and DVR solutions. Our solutions have been deployed worldwide among various applications including public transportation, school bus, law enforcement, private fleet, logistics management, railway and metro, mobile media operation, etc. We continue to enjoy rapid and steady growth and would like to invite you to be part of our global success. Please do not hesitate to pick up the phone or send us an email to find out how.

4 Channel sd card mobile  car  dvr digital video recorder for bus, truck, can, lorry,  car etc
