LT101 solar power tower warning light/solar warning light

Share on:


Price:RUB 78.58 - RUB 15,636.63
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

LT101solar power tower warning light

airport obstruction light

Product Description


Main functions and features

  • Based on LED technology,aviation special for red.
  • Base material is aluminum alloy, PC lamp housing, UV resistant, with bird spike.
  • Built-in photocell can switch ON/OFF the light at dawn and dusk.
  • With falling prevention device.
  • Buit-in Ni-MH battery, easy for replacement.
  • NO RF - radiation, EMC compliant.
  • Anti-vibration, corrosion resistance.
  • Working stable, low maintenance costs.
Specifications


International standard

ICAO(Aerodromes Annex 14)

Light source

LED

Light color

Red, (Amber, Green, Blue, White Optional)

Horizontal Divergence

360°

Vertical Divergence

≥10°

Flash settings

60time/min(other type can be customized)

Intensity

>10cd

Life time

≥100.000h

Solar Battery power consumption

1.8W

Battery Capacity

3.6V/8AH(Maintenance-free)NiMH

Continuous operation in rainy time

20 days





Battery protection way

Bottom dormancy switch(see notice)



Ambient temperature

-30℃~+70℃

IP Protection

IP65

Humidity

10%~95%

Material

Base:Aluminum  Housing:PC

Weight

2.3kg







Installation and Operation

  • Mount the solar light in the most suitable place such as under direct sunlight, to ensure its continuous operation.
  • Screw the lamp on the G3/4” threaded pipe, which should be fixed on a smooth surface with enough mechanical strength(see mounting drawing).
  • When first operation, if the solar does not light up in dark places, please put the light under direct sunlight for approx. 12hrs.
  • Please keep the light in a very dry and low temperature place, such as places with low humidity if do not use the light for a long time. Put the light under direct sunlight for three days every 40 days, to ensure the battery capacity.
  • Built in NiMH battery, after being used 450 times(15 months), the battery capacity is approx. 80% of previous capacities, at this moment, please replace the battery in time.

Installation Dimension(Unit:mm)

LT101-azcct solar power system lamp light hot new product.jpg



Installation Instruction

lt101-azsyt solar power system lamp light hot new product.jpg



Notice

  • The part of material of products is PC( like lamp cover and lamp shell ), so it cannot direct or indirect touch the organic solvent, such as industrial alcohol, banana oil, isopropyl alcohol, carbon tetrachloride, cyclohexanone and so on, otherwise, the product will be corroision.
  • Please read the instruction manual carefully before operation.
  • For protection of batteries during transport and storage, lights bottom installed sleep switch, and is set to sleep mode, please check whether the lamp is in normal working condition before installation or testing, turn on the switch according to the instruction.
  • the bottom of the switch control: Press 3 to 5 seconds, the light starts to sleep (stopped working); Press 1 to 2 seconds, the lights began to work); testing and operation of switches in the dark environments, or covered with black shade cloth in order to operate correctly.
  • Any question in operation please contact our company



Company Information

NANHUA Electronics Co., Ltd was founded in 1990, has been focused on developing, manufacturing and selling industrial signaling, lighting and controllers more than 27 years.



Based in Shanghai, China, NANHUA has a registered capital of RMB 50 million, with total about 285 employees (including 36 R&D people), and owned the production space of 120,000 square meters. As a high-tech enterprise in Shanghai, NANHUA has gained ISO9001, ISO14001 and OHSAS 18001 certificates.



Aviation obstruction lights as one of the major products of NANHUA, design and manufacturing according ICAO, FAA international and local CAAC standard, and most products have been certified.



NANHUA's products are widely applied in key projects domestic and abroad. NANHUA is committed to the establishment the benchmark of the top aviation obstruction light equipment.




Our Philosophy


NANHUA believes in a simple philosophy. We focus on providing the best products and service to clients and which is the reason for NANHUA’s existence. We believe that successful enterprise and employee fulfillment can only be realized by long-term hard working.


NANHUA pursues broad perspective and believes that imaginative work can change the world. We expect NANHUA to become an internationally competitive firm. Through constant hard work we anticipate a prosperous future.


NANHUA dedicates herself to creating an equal, free and open working environment. We respect each employee’s uniqueness and hope that all of them will work happily in NANHUA.



Features of Aviation obstacle lights (FAA)




Features of Aviation obstacle lights (ICAO)

Light Type

Colour

Signal type/

(flash rate)

Peak intensity(cd) at given Background Luminance(b)

Day

(Above 500cd/m²)

Twilight

(50-500cd/m²)

Night

(Below 50cd/m²)

Low-intensity,Type A

(fixed obstacle)

Red

Fixed

N/A

N/A

10

Low-intensity,Type B

(fixed obstacle)

Red

Fixed

N/A

N/A

32

Low-intensity,Type C

(mobile obstacle)

Yellow/

Blue

Flashing(60-90fpm)

N/A

40

40

Low-intensity, Type D

(follow-me, vehicle)

Yellow

Flashing(60-90fpm)

N/A

200

200

Low-intensity, Type E

Red

Flashing

N/A

N/A

32

Medium-intensity,Type A

White

Flashing(20-60fpm)

20 000

20 000

2000

Medium-intensity,Type B

Red

Flashing(20-60fpm)

N/A

N/A

2000

Medium-intensity,Type C

Red

Fixed

N/A

N/A

2000

High-intensity, Type A

White

Flashing(40-60fpm)

200 000

20 000

2000

High-intensity, Type B

White

Flashing(40-60fpm)

100 000

20 000

2000
