transformers 208v to 400v three phase power transformer



Transformer Features

Our transformers have special advantages and very different from others.

(1) All new raw materials.

(2) Full (100%) capacity.

(3) Low core loss with maximum efficiency and efficiency up to 99% reduces operating cost by 30%.

(4) Ultra quiet operation.
(5) Clear, comprehensive documentation and labeling.

(6) THREE YEARS warranty!

REMARK:

---Frequency CANNOT be converted by transformer.

---Single phase voltage to 3 phase voltage CANNOT be achieved via transformer.

Technical Parameters

In order to give you the best price, please kindly specify your requirements as clearly as possible.

OEM and ODM is welcome, we have professional and experienced engineer team for you.



Transformer Type

Isolation transformer/auto transformer, etc

KVA Rating

1-1200KVA

Primary

208VAC, 3 phase

Primary Taps

None

Primary Connection

Wye/Delta/Z, etc

Secondary

400VAC, 3 phase

Secondary Taps

None

Secondary Connection

Wye/Delta/Z, etc

Working Frequency

50Hz/60Hz

Vector Group

YY0/DYN11, etc

Winding Material

Aluminum/copper

Cooling Class

AA/FA

Insulation Class

F/H, etc

Temperature Rise

150℃/180℃, etc

Insulation Resistance

≥2MΩ

Dielectric Class

No damage at 2.5KV for 1 minute

Impedance Percentage

4%

Efficiency

≥99%

Duty Cycle

Continuous

Ambient Temperature

-15 to +45°C

Relative Humidity

0-95% (Non-condensing)

Altitude

≤5000m

Enclosure

None/NEMA 1, etc

Enclosure Color

None, white, black, etc

IP Rating

IP00/IP20 for indoor/IP54 for outdoor, etc

Special Requirements

Please advise before quotation

Processing Equipment

Our transformers are setting new standards for quality – in design, manufacturing and testing.

isolation ttransformer.jpg

Finished Transformer
Without or with enclosure (1.5-2mm thickness).
step down transformer.jpg
Pre-shipping Tests

Before leaving the LINGFRAN factory, every transformer must pass a series of rigorous tests, performed with advanced equipment, on a range of measurements.

(1) Appearance – visual check.
(2) Winding resistance.
(3) Insulation impedance.
(4) Voltage ratio. Phase angle displacement.
(5) Short circuit impedance and load loss.
(6) No load loss and current.
(7) AC voltage regulation.

Below are part of our testing instrument.

step up transformer.jpg
