A axis 80 chuck and thimble 4th axis 100mm rotary table 4th axis for 1520 3040

Share on:

Price:RUB 14,762.79
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

80mm chuck with motor
Overall dimension: 204*168*100mm
Chuck model: K1-80 (can choose K1-100) hand tight three-jaw self-centering chuck
Center height: 65mm
Total height: 100mm
Transmission ratio: 6:1(Synchronous speed reduction)
Stepper motor: 2 phase 4 wire nema 23
Accessories: a set of claw and a set of wrench
Weight: 2.5KG


1. Center height: 65mm
2. Total height: 93mm
Weight: 2.5KG
3. Top positioning self-locking, removable, free replacement of various types of Mo-2 top.
4. Telescopic rotary tip, maximum retractable length 35mm stable operation, small offset.

Application Areas
Production process
winding line
stator waveform check
wiring
R cover assembly
F cover assembly
driver a screw
magnetizing
characteristic check
axis height check
visual inspection
attach a label
packaging
