10KV vacuum interrupter embedded poles for vs1 circuit breaker

Share on:


Price:RUB 10,989.38 - RUB 16,280.56
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

10KV vacuum interrupter embedded poles for circuit breaker

embedded pole





Main techical data:
Rated Voltage: 12kv
Rated current: 1250/1600A
Rate frequency: 50Hz
Rated short-time power frequency withstand voltage(1min) 48kv
Rated lighting implus withstand current85kv
Rated short-time withstand current(4s)25/31.5kA
Rated peak withstand current 63/80kA
Rated short-circuit current63/80kA
Rated short-circuit breaking current25/31.5kA
Breaking operations of rated short circuit breaking current30 times
Rated single capacitor bank breaking current *630A
Rated back-to-back cap acitor breaking current400A
Mechanical life30000times
Contact closing force due to bellows and atmosphere100±30N
Counterforce at rated contact stroke200±30N
ciruit resistance at rated contact force≤20μΩ
Shelf life20 years
Contact erosion limit3mm
Part discharge≤2pC


Mechanical Date Required for Matched Vacuum Switchgear
Rated contact strok9±1mm
Contact connection stroke4±1mm
Average opening speed1.1±0.2m/s
Average closing speed0.8±0.2m/s
Added contact force3000±200N
contact bouncing duration at closing operation≤2ms
Out of simultaneity of contact closing and opening≤2ms
Max.overtravel≤2mm
Note:* Rated characteristics be given on request
