Fireproof high quality calcium silicate board for ceiling partition
Artificial House, And Also Made Man.
Calcium Silicate Board is a composite material made of quartz sand, cement and cellulose fibers. It is used for ceiling, interior wall partition and etc. The normal size is 1220×2440mm,thickness from 4.5~15mm, and density is 1.2~1.6g/cm3. There are low-density, middle-density and high-density.
Main Characteristic :
1. 100% Asbestos Free
2. Fire Resistance and Moisture Resistance
3. High Strength and Good Stability
4. Anti Fungus and Antiseptic
5. Widely used in Partition and Suspension System.
6. Easy working
Physical Property :
Fireproof Material price 10mm high density heat insulation fire rated calcium silicate board
|thermal conductivity||≤0.29 W/(m.k)|
|bending strength||average||>12 Mpa|
|Sanle calcium silicate board is for indoor partition and ceiling of moisture proof and fire proof in the wet area building.It is extensively used in office building, hotel, hospital, factory building, school, villa, theatre and other kinds of art building.|
Product Installation :
Partition Installation Method
1. Cutting the board material to the dimensions needed (about 10mm lower than wall height)
2. Board material is fixed on keel in anchoring seam way with tapping screw: the interval of tapping screw is generally
about 200~250mm with screws sinking 0.5mm under the board face.
3. The expansion seam of about 4mm between boards should be kept.
4. The shrouding should be fixed from the middle to the four sides and cannot be operated at multipoint simultaneously
to avoid generating inner stress to make board material bucking.
5. Before board being packaged and fixed, depending the needs, glass cotton or rock cotton can be filled.
Ceiling Installation Method
2.Connect and fix the boom and main keel with hanging piece to make the main keel keep level position.
3.Vertically fix the sub-keel to the main keel with hanging piece; the sub-keel axis’central range is 612mm.
4.Install the laterally supporting keel properly, its central ranges is 1224mm.
5.Fix the board on sub-keels with tapping screws, and to well the seam-connecting treatment.
The hanging system of Sanle board combined with light steel keel is divided into two kinds of person-standing type
and non person-standing type; for the non person-standing type,only consider the self-weight of ceiling and light.Lamp
without loading other loads; for the person-standing type. Consider about 80~100kg load when someone repaired it.
