1. General Specifications:
1) Single-layer Wall and single door, All-steel modular structure
2) Outer Dimensions: 1.2*1.2*2.3m
3) Outer Area: 1.44m 2 ;
4) The thickness of the wall is about 60mm.
5) The size of the soundproof booth window is 380×600mm.
6) With this specification, the cost on space and materials are
minimized while the soundproof effect is guaranteed.
7) Electrostatic spraying technology is applied to the exterior wall
surface while a polyester fiber sound absorbing panel is used for
the interior wall.
2. Implementation Standards:
1) Indoor background noise ≤30dB(A);
2) Comply with National Standards GB/T16403;
3) Comply with GB50325-2001 "Code for Indoor Environmental
Pollution Control of Civil Building Engineering";
4) Comply with GBJ304-88 "Qualification Inspection and Evaluation
Standard for Ventilation and Air Conditioning Engineering", and
the air exchange capacity is 6-10m 3 /min.
3. The soundproof booth is a modular structure as a whole and has
three key functions which are vibration isolation, sound insulation and
sound absorption. It also has the other functions such as ventilation,
noise reduction, lighting, power distribution, signal transmission,
moisture proofing, mildew proofing, and moth proofing, etc..The floor
is carpeted. The consumable parts are easy to replace, beautiful and
economical while meeting the requirements of fire protection
4. Service Life ≥10 years
Packaging & Shipping
Wooden Case Packaging
Warranty: 1 year
On-line after-sales service is always available.
