Permanent Stainless Steel Cathode Plates/titanium Cathode Plates

SS Cathode Plate.jpgSS  starting sheet.jpgti cathode plate  (1).jpg



Elegant Group is the most professional company in China to provide our clients with top quality Cathode plates and Anode plates for nonferrous metallurgy. In the past years, Elegant stainless steel/ titanium cathode plates, lead anode plates, aluminium anode plates are widely used in domestic and overseas Copper, steel, gold, nickel, zine, Cobalt and Manganese electrowinning/electrorefining /electrolysis plant for its excellent performance as below:




1. The connection area between Copper and SS is considerable, thus contribute to a less lose of electric power.

2. High mechanical strength design of hanger bar to prevent scratching, sinking mark and bending.

3. Hanger bar designed with good heat resistance to avoid deformation or degenerate, hanger bar can resistance high temperature up to 700 degree cause by short circuit.

4. The laser welding between SS blank/ Titanium plate and hanger bar can help avoiding the welding gap, thus can maximum prevent welding corrosion. The average service lifetime of cathode is 10-15 years.

5. By powerful extrusion, the edge strip is deformation free with long lifetime and easy for maintenance.

6. The performance of edge clip bar was stable which can decrease the cost.



Cathode is widely used in Zinc, Copper, Nickel, Cobalt and Manganese EW/ER industry. Copper can be easily deposit on the stainless steel cathode surface and be stripped by auto-stripping machine. The use of stainless steel cathode can save a lot of time and human cost compared to starting sheet. It's an obbligato part in large scale and modernization Copper electro-refinning and Copper electro-winning plant.



Material

Blank:

material - 316L stainless steel plate, Gr 1 or Gr 2 Titanium plate;

Hanger bar:

·Stainless steel cladding around copper bar(Cu-SS)

·Copper electro-plating stainless steel bar(SS-Cu)

·Triple layer (CS-Cu-SS)

·Al cladding Copper ingot, welding to Al bar

·Titanium clad copper bar (Ti- Cu)



Edge strip:

·PP by mechanical process or extrusion

·Advantages

·High strength and anti-corrosion hanger bar

·Advanced edge strip with round bar for fastening

·Special surface polishing treatment to form a passive film

·90 degree vshape groove at bottom of blank, Copper cathode

·can be more easily stripped in the bottom

·10~15 years service lifetime of blank, 1.5 year of edge strip

·Double side full welding technology


Welding
Perfect welding technology (Double-side full laser welding) is used to connect stainless steel blank / Titanium plate with hanger bar. It does not use flux to connect, which is successful to avoid the weld seam defects and maximize preventing corrosion.


Packaging & Shipping

 1. plastic films inside;
2. for small size plate: carton boxes or wooden cases outside
3. for big size plate: pallet or Iron steel frame packing
4. according to your requirements

TITANIUM CATHODE PLATE (8).jpgTITANIUM CATHODE PLATE (4).jpgTITANIUM CATHODE PLATE (6).jpg

Our Services



 1, We could produce high quality  stainless steel cathode plates/ titanium cathode plates, lead anode plates, aluminium anode plates

2, the shape, the size, the material according to customer demand

3, No MOQ

4,  24 -7 service

Company Information

 Corrosion-resistant metal composite material manufacturer
Caustic environmental protection equipment expert
Titanium/SS clad copper/Al bar/sheet/wire/tube leading provider
