Hand operated manual lifting lever hoist chain kawasaki hand pulley lever chain Block (60870056894)

Share on:


Price:$17.00 - $55.00
Price in USD:Details

Quantity:


Product Overview

Description



Product Description







HSH-A Ratchet Lever Hoist Manual Chain Pulley with factory price








Technical Features


1. One touch operation free chain adjustment


2. Grade 80 alloy load chain ISO and GES standard


3. Forged and heat treated load hooks with batch trace ability and stretch indicators


Idling operation


1. Depress the retaining pawl all the way and pull the grip ring towards you.


2. The chain can be adjusted up and down by hand.


3. To terminate the idling: Set the change lever in the down position (See diagram as below). Then, depressing the retaining pawl as far as possible, push the grip ring gently so as to let the pawl engage the outer edge of the retaining plate. Next, grip the grip ring and handle with a single hand and push them while turning them while turning them counter-clockwise. The retaining pawl returns to its original position.





* The specifications on this leaflet may be modified for improvement without notice.





Tested according to EN13157-2004


















































































































Product code



Capacity


(t)



Standard lift


(m)



Test load


(t)



Pulling Efforts


(kg)



Chain fall No.



Load chain Dia.


(mm)



Dimensions(mm)



Net Weight


(kg)



A



B



C



D



E



HSH-A075



0.75



1.5



1.13



15



1



6.3



148



128



295



256



45



6.9



HSH-A100



1.00



1.5



1.50



20



1



6.3



152



128



310



256



48



7.0



HSH-A150



1.50



1.5



2.25



18



1



7.1



161



148



335



368



52



9.6



HSH-A200



2.00



1.5



3.00



24



1



7.1



168



148



350



368



60



10.1



HSH-A300



3.00



1.5



4.50



38



1



9



191



180



405



368



66



15.9



HSH-A600



6.00



1.5



9.00



39



2



9



191



180



550



368



80



25.7



Individually proof load tested with individual serial number








  VITAL VL750VITAL VL750-1VITAL VL750-5


VITAL VL750-4.jpg


VITAL VL750-2.jpg


VITAL VL750-3.jpg












Packaging & Shipping


 VITAL VL750-6
