KAISHAN KSCY-580/17 Diesel Engine Air Compressor For Drilling Borehole

Share on:

Price:RUB 1,721,671.06
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

KAISHAN KSCY-580/17 Diesel Engine Air Compressor For Drilling Borehole












Kaishan brand movable air compressor for drilling borehole is reliable, the variety is complete, the exhaust volume coverage to 35m3/min, the discharge pressure of up to 2.5MPa.

Our movable air compressor for drilling borehole is used to power pneumatic tool and machines such as pneumatic breaker, jack hammer, drilling machine, oil cleaning machine, sandblasting machine, drilling rig and so on.



Detail Information of KSCY-580/17 air compressor for drilling borehole:



Model No.

KSCY-580/17

Capacity

17 m³/min (580cfm)

Working pressure

17bar (247psi)

The head model no.

SKY11G165

Air compressor oil capacity

48L

Compression Stage:

Single

Noise level db (a)

80±3

Outlet connection size*Qty

G2*1,G¾*1

Engine



Engine Model No:

Cummins 6CTA8.3-C260

Cylinder bore stroke number

of cylinders

114*135*6

Delivery Capacity

8.3L

Rated RPM

1800r/min

Unload RPM

1400r/min

Rated Power

194KW(260HP)

Diesel engine oil Capacity

21.9L

Fuel Tank Capacity

380 L

Electrical System Voltage

24V

Package



Wheel size * Qtys

7.5-16*4

Weight

3200KGS

Dimension (mm)

3600*1800*2450










Characteristics of air compressor for drilling borehole:

The diesel air compressor for drilling borehole is adopted with YUCHAI & Cummins & Deutz diesel engine

Direct coupling screw airend

SKF bearing match with SKY series airend




Efficient economic regulating system

Adjust the air consumption automatically to save energy

Operation panel of diesel compressor is easy to operate and can start when you stir the igniting switch.

1-2 years warranty period for whole machine, 5 years for air end.

Automatic protection system

Excellent components, Germany oil filter and electronics for high performance

Air filtration system with vacuum indication for dust environments







Certifications :

LG screw air compressor.jpg CE certificate.jpg







If you are interested in our movable diesel air compressor for drilling borehole please feel free to contact us and you will be get replied in 12 hours!
