DPSW-360 автоматическая высокоскоростная блистерная упаковка/Сумка для подушек/машина для картонного бокса все-в-одном, производственная линия для упаковки лекарств

Share on:


Price:
Price in USD:Details

Quantity:


Product Overview

Description


Product Description

01 Product Information

 DPSW-360 1



  Characters:

  • Visible tempering glass cover, easy to observe working status and maintenance. machine stops when cover is open.
  • Movable HMI, easy to test; multiple emergency stop buttons on whole working line.
  • Whole working line controlled by servo motion control system, with memory function, no need to reset parameters when machine stop or power interruption, continuous working following last recorded position.
  • Positioning mould, easy to change.
  • Buffer for blistering section, reducing contraction ratio of blister.
  • Integrated air and water cooling station.
  • Wasted edge chopping and discharging, no need machine stopping and collecting.
  • Hard connecting for upstream and downstream equipment, continuous eeding, instant setting in HMI for various blisters and wrapping package quantities.
  • Two film stations for wrapping packaging, no need machine stop when changing film.
  • Cutter plated with special surface layer, no material sticky to cutter.

  Main Technical Parameter

Total power380V 50HZ 25KW
Air pump≥0.25m³/min (self-prepared)   0.6-0.8Mpa
Size14800*1200*1740mm (Can be packaged separated)
Weight7000kg

DPP-300K Blister Packing Machine
Punching speedAL/PVC: 150 cuts/min   AL/AL: 60 cuts/min
Max. forming area & depthAL/PVC: 200*300*15mm   AL/AL: 200*300*12mm
Travel scope30-120mm

Packing material

(Roll dia φ75mm)

PVC sheet: (0.15-0.4)*310*φ600mm
Heat-sealing Aluminum foil: (0.02-0.15)*310*φ300mm
Forming Aluminum foil: (0.16-0.2)*310*φ600mm
Heat-sealing dialyzing paper: (50-100)g/m2*310*φ300mm

GS-500 Pillow Type Machine
Capacity30-180 bags/min
Packing sizeCutting size: 75-400mm
Packing film width: Max. 450mm
Product size: Max.width: 200mm   Max.height: 60mm

ZH-360 Cartoner
Speed360 boxes/min
Carton quality250-350g/m2
Carton size(90-160)*(40-100)*(16-30)mm
Leaflet quality70-80g/m2
Leaflet unfolded size scope (1-4 Fold)(130-250)*(100-180)mm



DPSW-360 2

DPSW-360 3

DPSW-360 4

DPSW-360 5





Company Information

02-1 Company Profile

02-2 Company Profile

Our Services

03-1 Our service

03-2 Our service

03-3 Our service

03-4 Our service (2)

FAQ

04 FAQ



Q: Are you really a manufacturer? Where is your factory? How can I visit your factory?
A: Sure, we are a source manufacturer, Zhejiang Jiangnan Pharmaceutical Machinery Co.,Ltd. SINCE 1997. Our factory is located In Rui'an city, Zhejiang province. We warmly welcome you to visit our factory if you have a travel plan.

Q: How can I know if your machine is designed for my product?
A: Don't worry, you can send us your rough draft or product design. We will confirm with engineers and designers. After the machines are done, we will take videos and clearer pictures for you. We can also show you on-line by video chatting. And the machines will be adjusted well before shipment.

Q: How can I trust you for the first-time business?
A: Please note our business license and certificates above. If you don't trust us, we suggest using Alibaba Trade Assurance Service for all transactions to protect your money and ensure our service for you.

Q: How about the after service and guarantee period?
A: We offer 12 months warranty since the arrival of the machine. Overseas technical support is available. We have professional team with experienced technician to serve abroad and do the best after service to assure the machine whole life usage.

Q: How to contact you?
A: You can click at the "contact supplier" to contact online persons. We are always here for you.

Need more machines details and videos? Please contact us directly!

Packaging & Shipping

05 Packaging & Shipping
