60m outdoor perimeter infrared photoelectric 2 beam detectors

Share on:

Price:RUB 903.23
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Brief introduction

60m outdoor perimeter infrared photoelectric 2 beam detectors

1.The Active Infrared Beam Detectors utilize invisible Infrared barriers to detect the intrusion. It has long detection/guarding range, low-cost, high-quality, and installation-friendly features.
2.Our beam detectors adopt 8-channel frequency design to avoid IR interference between different beams, this can greatly reduce the false alarm rate to offer you accurate motion detection.
3.These photoelectric beam detectors have N.O. and N.C. alarm output, can work with difference systems through reliable wired connection. It's the ideal security detectors for your intrusion alarm system, access control system, IP surveillance system and home automation system.

Structure

2 beams infrared detector.jpg



Features

1. 2 beams active infrared detector: can reduce the false alarms that are caused by bird, pet leaf...etc.

2. Selectable frequency 8 channels: Stacking, Straight line, Square or other various applications are allowed.
3. LED display signal grade for easy alignment.
4. Adopt digital DIP technology, frequency, sensitivity, indicator and operation power can be adjusted through DIP switches.
5. Special-purpose DSP chip, patent multidimensional fault-tolerant, true detection alarm technology.
6. NC/NO relay outputs, compatible with other brand alarm systems like Honeywell, Bosch, Paradox, DSC, GE Alef, HONEYWELL etc.

7. Anti-glare up to 50,000 LUX, built-in automatic adjustment strong light filtering system.

8. AGC circuit: when faced with fog or inclement weather,t he detector sensitivity will increase automatically.
9. Fully seal structure, with rain cover design, C relay output.

10. External Protection: Protection from rain, dust & insects.
11. Sniper viewfinder with x2 magnification

12. Horizontal ±90° / vertical ±10° optical angle can be easy to adjust.



 Parameters



Model

ABT-40F

ABT-60F

ABT-80F

ABT-100F

Detection Range

Outdoor

40m

60m

80m

100m

Indoor

120m

180m

240m

300m

Maximum Arrival Distance

250m

350m

500m

600m

Number of beams

2 beams

Detection Method

Simultaneous blocking of 2 infrared beams

Interruption Time

50msec, 150msec,300msec,500msec (selectable)

Beam frequency

8 channel selectable

Power Supply

DC10~36V;  AC8~24V

Current Consumption

50mA max

50mA max

55mA max

55mA max

LED

Red LED Alarm(receiver), Digtal LED Display

Alarm Output

Form C, Contact capacity: AC / DC30V, 0.5A or less

Tamper Switch

N.C., open when cover is removed

Fault Alarm(optional)

N.C Fault Output when the signal is incompetent

Operating Temperature

-25℃ to +55℃

Environment Humidity

95% max

Alignment Angle

Horizontal 180°(±90°), Vertical 20°(±10°)

Mounting

Wall or Pole

Protection Degree

IP65

Material

PC engineering plastic

Dimension (L*W*H)

220*80*75mm

Weight (Transimtter and Receiver)

900g

Attachments

U bracket

2pcs, 70.4*37.5*21.5mm, δ=1.5mm, stainless steel

Pole mounting srew

Pole mounting screws: 4pcs, PM4*30mm

Wall mounting screws: 4pcs, PM4*25mm

Installation manual1
Spiral Terminal Dedew and Defrost MethodHeaters(need to purchase separately)
Note: When environment termperature lower than -20℃, please use heaters to ensure normal working. Heater is non-polarized.



Product Description

2 beam detectors (2).jpg2 beam detectors (3).jpg2 beam detectors (4).jpg2 beam detectors (5).jpg2 beam detectors (6).jpg2 beam detectors (7).jpg2 beam detectors (8).jpg2 beam detectors (1).jpg



How to connect to wired alarm system?

connect to alarm system.jpg
