AR7000 gsm gprs modem is a kind of terminal device that developed based on 2G/3G/ 4G, WIFI, VPN technology.It adopts high-powered industrial 32-bits CPU and embedded real time operating system. It supports RS232 (or RS485/RS422), Ethernet and WIFI port that can conveniently and transparently connect one device to a cellular network, allowing you to connect to your existing serial, Ethernet and WIFI devices with only basic configuration.
Related Products
Highlights
Failover between SIM/UIM card and wired network.
Strong signal.
Industrial grade design.
High efficient and stable VPN.
Specifications
| Items | Contents |
| | CPU | Industrial 32bits CPU |
| FLASH | 16MB (Extendable to 64MB) |
| SDRAM | 128MB |
| | WAN | 1 10/100Mbps WAN port(RJ45) |
| LAN | 4 10/100Mbps Ethernet ports(RJ45) |
| Serial | 1 RS232(or RS485/RS422) port |
| Antenna | Cellular: Standard SMA femal WIFI: Standard SMA male
GPS(optional):Standard SMA female
|
| | | GSM/GPRS/EDGE: 850/900/1800/1900MHz
WCDMA/HSUPA/HSPA+: 850/900/1900/2100MHz
TDD-LTE: Band 38/39/40/41& Band 61/62
FDD-LTE: Band 1/2/3/4/5/7/8/13/17/20/25/28/66 |
| | Receiver Type | GPS L1(1575.42MHz)C/A code
SBAS: WAAS,EGNOS,MSAS,GAGAN |
| Accuracy | Position: 2.5m CPE
SBAS: 2.0m CPE |
| | Standard | IEEE802.11b/g/n |
| Bandwidth | IEEE802.11b/g: 54Mbps (max) IEEE802.11n: 150Mbps (max) |
| | Standard Power | DC 12V/1.5A |
| Power range | DC 5~35V |
| | Dimensions | 186.8x120.2x28mm |
| Weight | 580g |
| Temperature | Operating Temperature | -35~+75ºC (-31~+167℉) |
