EASUN POWER 3000W 230Vac 24Vdc 80A Bluetooth 3000VA Hybrid MPPT Solar Power Inverter with 500Vdc PV Input

Share on:

Price:RUB 30,215.97
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

SMV-III-3K_01



Product Description

Main Features

  • Max 3KVA/3KW output solar inverter for 24VDC systems
  • Removable LCD control display (20M)
  • Built-in Bluetooth for mobile monitoring(Android App is available)
  • Max 80A MPPT solar charger,Max Solar Power 4000W
  • Built-in  60A battery charging with EQUALIZATION feature
  • Total system max charging: 120A
  • Adjustable AC input voltage 90~280VAC
  • Supports 50hz or 60hz via LCD program
  • transformerless, light weight design
  • Built-in alarms and protections
  • fuse protection (against dc reverse polarity)
  • Removable USB + RS232 + RS485 + Bluetooth communication port
Specification



MODELISolar SMV III 3K-24ISolar SMV III 5K-48
Rated Power3000VA/3000W5000VA/5000W
INPUT
Voltage230 VAC
Selectable Voltage Range170-280 VAC (For Personal Computers)
 90-280 VAC (For Home Appliances)
Frequency Range50 Hz/60 Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Mode)230VAC ± 5%
Surge Power6000VA10000VA
Efficiency (Peak)90% ~ 93%
Transfer Time15 ms  (For Personal Computers)
20 ms (For Home Appliances)
WaveformPure sine wave
BATTERY
Battery Voltage24 VDC48 VDC
Floating Charge Voltage27 VDC54 VDC
Overcharge Protection33 VDC63 VDC
SOLAR CHARGER & AC CHARGER
Solar Charger typeMPPT
Maximum PV Array Power4000W
MPP Range @ Operating Voltage120 ~ 450 VDC
Maximum PV Array Open Circuit500 VDC
Maxmum Solar Charge Current80A
Maximum AC Charge Current60A
Maximum Charge Current80A
PHYSICAL
Dimension, D x W x H (mm)115 x 300 x 400
Net Weight (kgs)910
Communication InterfaceUSB/RS232/RS485/Bluetooth/Dry-contact
OPERATING ENVIRONMENT
Humidity5% to 95% Relative Humidity (Non-condensing)
Operating Temperature-10°C to 50°C
Storage Temperature-15°C to 60°C
Product Details

SMV-III-3K_02SMV-III-3K_03SMV-III-3K_04SMV-III-3K_05SMV-III-3K_06SMV-III-3K_07SMV-III-3K_08
