Pilot Scale Vacuum Distillation Essential Oil Distiller Cannabis Oil Extract 5L 10L 20L 50L Rotary Evaporator Hot Recommended (62117181637)

Share on:


Price:RUB 94,134.05 - RUB 332,769.36
Price in USD:Details

Quantity:


Product Overview

Description

Working Principle


An ( Explosion-proof ) rotary evaporator ( also called rotary vacuum evaporator or rotary devaporizer or rotovap or rotavapor or rotavap ) is used for purification and distillation test. They rotate and shape a thin film in negative pressure condition by heating, evaporate efficiently, and then condense and recollect solvent to purify and separate.

R1005

R1010, R1020, R1050


Application


1. An ( explosion-proof ) rotary evaporator ( also called rotary vacuum evaporator or rotary devaporizer or rotovap or rotavapor or rotavap ) is a device used in chemical laboratories for the efficient and gentle removal of solvents from samples by evaporation. It is widely applied in such experiments such as concentration, evaporation, distillation, separation of chemical, using the rotating bottle to dry the powder and crystallization and so on.

2. An ( explosion-proof ) rotary evaporator ( also called rotary vacuum evaporator or rotary devaporizer or rotovap or rotavapor or rotavap ) can be used with recirculating water vacuum pump and low temperature cooling liquid circulating pump/ recirculating chiller to form the total system.

Configuration


Technical Data


Model
R1005
R1010
R1020
R1050
Ambient temperature(℃)
5~35
5~35
5~35
5~35
Power Supply(V/Hz)
Single-phase 220/50
Single-phase 220/50
Three-phase 220/380/50
Three-phase 220/380/50
Speed-regulation of main machine
Digital display, variable frequency stepless speed-regulation
Digital display, DC stepless speed-regulation
Digital display, DC stepless speed-regulation
Digital display, DC stepless speed-regulation
Rotation speed (rpm)
10~140
20~130
20~130
20~110
Power of rotation motor(W)
40
Brushless motor,250
Brushless motor,250
Brushless motor,250
Temperature range(℃)
Digital display, Room Temperature -99
Digital display, Room Temperature -99
Digital display, Room Temperature -99
Digital display, Room Temperature -99
Max. vacuum degree(Pa)
399.9(Below 3mmHg)
399.9(Below 3mmHg)
399.9(Below 3mmHg)
399.9(Below 3mmHg)
Evaporating flask(L)
5, Flange opening Ø50

10, Flange opening Ø125

20, Flange opening Ø125

50, Flange opening Ø125

Receiving flask(L)
3
5
10
20
Condenser
Vertical type double coil pipe
Vertical type, Main + auxiliary triple-circulating cold traps
Vertical type, Main + auxiliary triple-circulating cold traps
Vertical type, Main + auxiliary triple-circulating cold traps
Condensation area(㎡)
0.27
Main condenser 0.42, Auxiliary condenser 0.22
Main condenser 0.8, Auxiliary condenser 0.39
Main condenser 0.91, Auxiliary condenser 0.52
Evaporating Speed(L/h)
Water≥2

Alcohol≥4

Water≥3.2

Alcohol≥6.5

Water≥5

Alcohol≥11

Water≥9

Alcohol≥19

Bath material
Stainless Steel
Stainless Steel
Stainless Steel
Stainless Steel
Bath Size(mm)
Φ300×170
Φ350×220
Φ450×260
Φ550×320
Lifting function
Motorized lift
Motorized lift
Motorized lift
Motorized
Elevating stroke(mm)
0~150
0~160
0~190
0~180
Overall Power(kW)
2.2
4.8
6.3
8.3
Dimension(mm)
860×500×1000
920×550×1700
1250×600×2100
1320×770×2340

Main Features


1). Teflon (PTFE) and fluorine rubber dual rotating seal to ensure high vacuum.

2). The introduction of foreign advanced frequency control system, temperature control system, accurate and reliable.

3). A vacuum switching valve, without affecting the system vacuum distillation of the situation and the solution can be continuously collected.

4). Water bath electric lift and manual lift support, easy to use.

5). PTFE draining valve, corrosion resistance, pollution-free.



Detailed Images
Corollary Equipments

1). -30 To Room Temperature Recirculating Chiller DL Series


2). 5L ~ 50L Rotary Evaporator R Series

3). Water Circulating Vacuum Pump SHB-B95 Series


CE Certificate
Packing & Delivery
