Glue Dispenser,semi-auto glue dispenser 982, Epoxy resin Dispensing Machine

Share on:

Price:RUB 4,533.36
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

Product Description



Model number BY-982
Typemanual handheld glue dispenser
Air source Max.0.99MPa
Output pressure 0.05MPa--0.99MPa
Output time 0.01-1s; 0.1-10s; 0.2-20s; 0.3-30s switch by adjusting DIP program
Vacuume Suction suction pressure control to 600mm mercury
Repeatability+-0.05%
Glue Flow Frequency600times/min
Minimum Glue FlowMinimum Glue Flow0.01ml
VoltageAC 220V±10%/50Hz
Power<8w
Working temperatureTemperature:5-40 degree. Humidity:20-90%RH
Size235*225*63mm
Weight2.2kg



 BY-982

Dispenser fittings include: one dispensing stand, three 30CC cylinders, one connecting air
pipe, one 30CC adapter, five needles, one foot switch and one power line.




1. Instructions
BY-982 Semi-automatic Glue Dispenser pushes out the liquid by high pressure air with foot pedal
at the set time. It can flexibly adjust the manual and semi-automatic motion. High precision digital
timer controls dispensing time accurate to millisecond; no waste of glue. Adjust air pressure and
dispensing time, select right needle, and you can control volume of glue flow and dispensing time.
Easy and fast operation solves lots of dispensing problems. Vacuum suction function controls glue
of varied viscosity to prevent dispensing leak, highly efficient. This dispenser is widely used in
many industries and it can be customized at request of customers.



2. Specifications
Voltage: AC 220V±10%/50Hz
Power: <8W
Air source: Max.0.99MPa
Output pressure: 0.05MPa--0.99MPa
Output time: 0.01-1s; 0.1-10s; 0.2-20s; 0.3-30s switch by adjusting DIP program
Function mode: manual/semi-automatic
Vacuum suction: suction pressure control to 600mm mercury
Repeatability: +0.05%
Glue Flow Frequency: 600times/min
Minimum Glue Flow: 0.01ml
Outer Size: 235mmx225mmx63mm
Weight: 2.2kg



3. Features
Digital timer
0.18CV constant flow electromagnetic control valve
Indicator lamp switch
Adjustable vacuum apparatus: suction 15 inches/ mercury column
Foot pedal
All spare parts available for sale


4. Applicable liquids
Adhesive, damping oil, epoxy, chemical reagent, scaling powder, cubond, silicone, grease, solder
mask, ink, paint, cellulose lacquer, solvent, etc.


5. Applications
Automotive electrical appliances, packaging, household appliances, bearings, circuit board,
electronic components, camera, medicine, electrical assemblies, capacitor, instrument, jewelry,
relay, quartz crystal, integrated circuit, light fixture, radio equipment, wireless connector, etc.

 by-982 (11)by-982 (1)by-982 (4)by-982 (7)



product list
 BY-21A (2)  (4) 20W (10).jpg
Our Service

1. OEM Manufacturing is welcome.

2. Sample order is accepted.
3. We will reply you for your inquiry within 24 hours.
4. After shipping, we will track the products for you once every two days, until you get the products.
5. When you got the goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer the solution for you.
6. The warranty of our products is 1 year.



FAQ

Q1. What is your packaging terms?
Usually, we package our products in color boxes and brown cartons. Provide a reasonable minimum order quantity of OEM services. If you have a legally registered patent, we can package the item into your brand box after receiving your authorization. The cost depends on the quantity.


Q2. What is your payment terms?
Western Union, T/T and Paypal are 100% advanced before sending the product. If you need additional terms, please discuss with our sales staff.


Q3. What is your shipping terms?
EXW. If you need additional terms, please discuss with our sales staff.


Q4. How is your delivery time?
In general, the number of 100 sets or less is only 2-10 working days. The exact delivery time depends on the model of the material, the stock of the material and the quantity of the order.


Q5. What is your sample policy?
We do not have a minimum order quantity for sample orders. And the sample order can enjoy the fastest lead time only one day after receiving the payment.


Q6. Do you test all the goods before delivery?
Yes, we performed 100% testing before delivery and all products were tested for at least 48 hours to ensure good quality.


Q7. How do you make our business a long-term and good relationship?
1. We maintain good quality and competitive prices to ensure customer benefits;
2. We respect each customer as our friend, we do business in good faith, make friends with them,
No matter where they come from.
