Laboratory Small Roller Ball Mill Equipment, Powder Roll Mill Machine

Share on:


Price:RUB 78,130.99 - RUB 127,560.80
Price in USD:Details

Quantity:

Add to Cart
  • add to wishlist

Product Overview

Description

Product Description
Laboratory Small Roller Ball Mill, Powder Grinding Roll Mill Machine


Overview:

Lab roll ball mill is a kind of equipment used for ultra-fine grinding and mixing for laboratory and small batch production. The machine is preferred equipment for scientific research, education, experiment and production due to its advantages such as elegant and fashion design, compact structure, easy operation, high efficiency, and uniform granularity. It is widely applied to industries of electronic material, magnetic material, biological medicine, ceramic glaze, metal powder, nonmetallic minerals, new materials, and etc.



Working principle:

When mill works, the grinding media and the materials inside the tank are rotated to a certain height. Due to the gravity, they fall down from the tube wall. Materials are crushed by impact action of the grinding media, friction and shearing action of grinding media’s rolling and sliding.



Features:
1. Compact structure, easy operation
2. High efficiency and uniform granularity
3. Milling pot in different size can be put on the driven rubber roller within a certain range by means of adjusting space between the rubber rollers.
4. It is convenient to change pots and suitable for both wet and dry grinding.

The Input & Output Size of material


For fragile materials:
Input size: 10mm maximum
Output size: 15um minimum
Time needed: About 3hours per time milling


For hard materials:

Input size: 3mm maximum
Output size: 15um minimum
Time needed: Depends on the material hardness.

Working Principle



Machine Characteristics

1. Compact Structure; Easy to operate;
2. Efficient working; Uniform grinding particle size by horizontal milling;
3. Applied to different size jars by adjusting the movable axises;
4. Convenient to exchange jars, applied for wet/dry mill.



Model
QM-1
QM-2
QM-3
QM-5
QM-10
QM-15
Jar Volume(L)
1
2
3
5
10
15
Power (W)
370
370
370
370
750
750
Rated Voltage(V)
220
220
220
220
220
220
Maximum Load (KG)
8
10
20
35
50
80
Speed Mode
Frequency Conversion Spped Regulation
Roller Speed    (r/min)
90-130
90-130
90-130
90-130
70-100
70-100
Size(mm)
730*415*260
730*415*260
730*415*260
730*415*260
840*435*270
840*435*270
Station Space  (mm)
260
260
260
260
340
340
Roller distance(mm)
250
250
250
250
270
270

Tank material

Ceramic, Stainless steel, Corundum, Polyurethane, Nylon, PTFE, etc.
Medium Ball
Alumina, Zirconia, Agate, Hardened steel, Stainless steel, etc.

Remark: (1) Single tank, feeding grain size: ≤10MM diameter, output grain size: 15μm minimum diameter.
                (2) Loading rate of ball mill can not exceed 70% of the effective volume of grinding cylinder.



Product Images











Our Company & Team



Certifications

Cooperative Partner



Packaging & Shipping

PACKAGE:

     1 Standard exported package: Internal anticollision protection, external export wooden box packaging.

     2 Shipping by express, by air, by sea according to customers' requirements to find the most suitable way.

     3 Responsible for the damage during the shipping process, will change the damage part for you for free.



DELIVERY TIME:15-20 days after confirming order,detail delivery date should be decided according to production season and order quantity.
