Product Overview

Description

CNBX High Quality white black self-locking plastic nylon cable tie

Banner

.jpg

Product Description

11






Material:

Nylon66(ULapproved material)

Structure:

Self locking head

Color:

White/black/nature standard color, other colors are available on request

Working temperature:

Applied from -40℃ to 85℃

Length:

All lengths are available

Feature:

Flame-retardant(94V-2), heat-resistant

Certificate:

SGS, RoHS, CE

Usage:

First, the cable is bundled in the nylon cable tie;

Next,the tail of the nylon cable tie is clamped by the tool;

Finally, tighten with tool

Application:

Used to bundle cables, wires, conducts, plants or other things in the industry of electrical & electronic, lighting, hardware, pharmaceutical, chemical, computer, machinery, agriculture, etc.

Delivery time:

3-15 days (Depend on your order quantity) after confirm order.

Payment terms:

T/T,Western Union,L/C ,PayPal





Part NoLength mm(inch)Width (mm)Bundle diameter E(mm)Min.Loop Tensile Strength
LBS KGS
3*100100(3.94)2.52~22188
3*120120(4.72)2.52-30188
3*150150(5.91)2.52-35188
3*200200(7.87)2.53-50188
4*120120(4.72)3.53-304018
4*150150(5.91)3.53-354018
4*200200(7.87)3.53-504018
4*250250(9.84)3.53-654018
4*300300(11.81)3.53-804618
5*120120(4.72)4.83-245022
5*200200(7.87)4.53-505022
5*250250(9.84)4.53-655022
5*300300(11.81)4.53-825022
5*380380(14.96)4.73-1025022
5*400400(15.75)4.73-1055022
5*450450(17.72)4.73-1305022
5*500500(19.69)4.73-1505022
8*200200(7.87)7.63-508555
8*250250(9.84)7.64-638555
8*300300(11.81)7.64-828555
8*350350(13.78)7.64-9012055
8*370370(14.57)7.64-988555
8*400400(15.75) 7.64-10512055
8*450450(17.72) 7.64-11812055
8*500 500(19.69) 7.64-15012055
