RCCB

Product Description



Function

Electro-magnetic release, voltage independent.

High ability of with-standing short circuit current

Visible-trip window: fault tripping is indicated by a red mechanical indicator on the front face

Insulated terminal: 1P+N, 3P+N

Contacts position indicating:

The green OFF mark on the handle indicates the cut-off of the circuit, guarantees the safety of down stream operation



Technical Parameter

Model name



EBS5R

Standard



IEC61008-1

Poles



1P+N, 3P+N

Rated current In(A)



25, 40,63A

Rated voltage Un(V)



230/400V AC 50/60Hz

Tripping sensitivities



AC

Insulation voltage (Ui)



500V

Rated impulse withstand voltage (Uimp)



6kV

Pollution degree



3

Installation



Installed on 35mm DIN rail



Applicable Working and bus bar connection

Ambient temperature



-5~+40℃, the average value cannot exceed to +35within 24h

Altitude



2,000m

Relative humidity



95%

Pollution level



II.

Installation location



Mount on the place where has no obvious vibration or impact
