8 inch Retina touch screen 2048*1536 resolution 5 in 1 cctv tester X9 MOVTADHS IP,CVI,TVI,CVBS,AHD camera tester

Share on:

Price:RUB 39,468.63 - RUB 40,151.74
Price in USD:Details

Quantity:

Add to Cart

Product Overview

Description

8 inch Retina touch screen 2048*1536 resolution 5 in 1 cctv tester X9 MOVTADHS IP,CVI,TVI,CVBS,AHD camera tester

Product feature





Camera test:

* 8 inch retina touch screen, 1920*1200 resolutions

*H.265 & H .264 IP, 4K video display via mainstream

* 8MP TVI test,3840 x 2160P 15 fps,4xzoom ,video record &playback ,coaxial PTZ control & call OSD menu *

* 5MP AHD test, 2560x1944P12.5F/ 20fps, 4xzoom, video record & playback, coaxial PTZ & call OSD menu *

* 8MP CVI test, 3840 x 2160P 12.5/15fps, 4xzoom, video record& playback, coaxial PTZ & call OSD menu *

* HD SDI/EX-SDI camera test, support 1080P 50/60 FPS *

* Rapid ONVIF, Auto log in and display image, create testing report

* Chrome browser, test and set Axis camera



* AXIS, Hikvision camera test, enter ONVIF app, input username and password to test

* CVBS camera test and PTZ control

* IPC TEST (Non-ONVIF test), HIK test tool (Hikvision camera), DH test tool (Dahua camera)

* Video level meter, peak video signal level, SYNC signal level, Color bar chroma level measurement

*DC12V/2A power output, camera can be powered from DC 12Votage

*48V PoE power output power

*Rapid video, just by one key to detect all network cameras and auto display

*Built in Wi-Fi, display image from the wireless camera, create WIFI hotspot

*CVBS loop test, the tester send and receive color bar generator signal, to check BNC cable

* Enhanced Color bar generator, PAL/NTSC multi-system color bar video generator

Cable test:

*Improvement cable tester, UTP cable, telephone cable etc order and connectivity test, can save testing report, if special number, need customized

  * RJ45 cable TDR test, test cable pair status, length, attenuation, reflectivity, impedance, skew etc

 * Cable tracer, search BNC cable, network cable and telephone cable from the mess cables *

Other functions:

* Network tool: Ping, IP scan, Port Flash, DHCP server, Trace Route

* POE & power information, DC12V& PoE power and voltage output /input measurement

* TesterPlay: Tester, android version mobile phone and PC display at the same time

* Shortcut button, drop-down menu, can select Poe power, IP setting, CVBS, LAN info, HDMI IN etc

* HDM input,720×480p /720×576p /1280×720p /1920×1080p /1024×768p/1280×1024p /1280×900p /1440×900p display,record and snapshot *

* Traffic monitoring, display network port or WIFI connection real-time upload and download speeds and other network parameters

* Self -update software, you can install apps with android version

* Media player, 4K video files and MKV/MP4 media files play

* Quick office, quick office app (support excel, word, ppt format) doc. editable

* 8GB SD card including

* Display its genuine resolution of the IP camera images

* Audio in, support record and save the audio/LED lamp, calculators, music players and other application tools

* 7.4 V /7000mAh Lithium Ion Polymer Battery, after 6~7 hours charging , working time lasts 16 hours



More Function can Add:



X9-ADHadd  AHD(A)/CVI(D)/TVI(H) image display,support the coaxial visual control calls to set up the camera menu.support HDMI input,1080P.$353
X9-ADHSadd  AHD(A)/CVI(D)/TVI(H)/SDI(S) image display,support the coaxial visual control calls to set up the camera menu.support HDMI input,1080P.$388
X9-MOVTADHSadd Digital Multimeter (M)/Optical power meter (O)/Visual fault locator (V)/TDR cable test (T). support Cable tracer,Video level meter.
add AHD(A)/CVI(D)/TVI(H)/SDI(S) image display,support the coaxial visual control calls to set up the camera menu.support HDMI input,1080P.
$529
Product show





QQ20180224151530.jpgQQ20180224151648.jpgQQ20180224151732.jpgQQ20180224151753.jpgQQ20180224151837.jpgX9--.png







details



LCD

Item series

                                  X9 series

Size & Display resolution

New 8 inch touch screen with retina display ,2048*1536 resolution

  Video Mode

 CVBS

1 channel BNC input & 1 channel BNC looped output, NTSC/PAL (Auto adapt)

Analog video level meter, peak video signal level, SYNC signal level, Color bar chroma level measurement



PTZ control, RS485 control, Baud 600-115200bps, Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, etc



CVBS loop test

the tester send and receive color bar generator signal, check BNC cable



IP camera test

IPC test /IPC viewer /Rapid Video/RTSP /ONVIF



Rapid Video

can create testing report



Hik test tool

pressing just one key to activate hikvision camera , Image test, can modify the user name, password and IP parameters



Dahua test tool

Dahua camera test, modify the user name, password and IP parameters



IP& CVBS test

IP& CVBS test at the same time, converter test from analog to digital with dual test window



 HD Coaxial test *

8MP TVI camera test,3840 x 2160P 15 FPS, UTC control/ call OSD menu



8MP CVI camera test: 3840 x 2160P 12.5/15 FPS,UTC control d call OSD menu



5MP AHD test,2592 x 1944P 12.5/20FPS, UTC control d call OSD menu



HD SDI/EX-SDI camera test ,support 1080P 25/30/50/60 FPS



HDMI input

1 channel HDMI input,support1080P



Zoom Image

4x zoom, to enlarge image, Screen snapshot, record ,save ,view and record and play back



Analog Video out

Color bar generator

Output one channel PAL/NTSC color bar video signal for testing monitor or video cable



HDMI output

1 channel HDMI output, support 1920*1080P





12V/3A power output

Output DC12V/3A power out ,supply temporarily power for the camera



Power output



PoE power output

48V PoE power output, max power 24W



5V/2A power output

USB 5V 2A power output, as a power bank



 Cable test

TDR cable test *

BNC cable, network cable, telephone cable, RVV cable and elevator cable, cat 5/6 cable’s length and short circuit. measurement range 1.2KM



Cable tracer

search BNC cable, network cable and telephone cable from the mess cables



UTP cable test

Test UTP cable connection status and display on the screen. Read the number on the screen



RJ45 cable TDR test

test cable pair status, length, attenuation, reflectivity, impedance, skew etc



TesterPlay

screen projection: tester, android version mobile phone and PC display at the same time



Network test

Trace route, Link monitor , DHCP server, port flashing , Ping test



Wi-Fi

Built in WIFI,speeds150M,display wireless camera image

Audio test

1 channel audio signal input, test whether sound normal, 1 channel audio signal, to connect headphone

Data monitor

Captures and analyzes the command data from controlling device,also can send hexadecimal

PoE test

Measurement POE switch or PSE power supply voltage and cable connection status

Drop-down menu

You can select PoE power switch ,IP setting, WLAN switch , HDMI IN functions etc in any interface

External power supply

DC 12V 2A

Battery

Built-in 7.4V Lithium polymer battery ,7000mAh

Rechargeable

After charging 6-7 hours, normal working time 16 hours

Operation setting

OSD menu, select your desired language: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish etc

Auto off

1-30 (mins)

Working Temperature

-10℃---+50℃

Working Humidity

30%-90%

Dimension/Weight

264mm x 182mm x 43mm / 1Kg

Below functions are customizable,MOQ is 50pcs (If add any below function into tester, you need pay addition cost),full model is X9-MOVTADHS

M*

Digital Multimeter :DC and AC voltage measurement, Resistance measurement, Continuity test, Diode measurements, Capacitance measurement

O*

Optical power meter, Wavelength:1625,1550nm,1490nm,1310nm,1300nm,850nm, measurement range ,-70 ~ +10 dBm, for optical power testing and Fiber link loss relative measurement

V*

Visual fault locator :10mW visual fault locator with 650nm wavelength can emit red laser sources to test multi-mode and single mode fiber’s bending and breakage, test range 10KM

T*

TDR cable test: BNC cable, network cable, telephone cable, RVV cable and elevator cable, cat 5/6 cable’s length and short circuit. measurement range 1.2KM

ADH*

8MP TVI ,8MP CVI ,5MPAHD test

ADHS*

8MP TVI ,8MP CVI ,5MP AHD ,HD SDI/EX-SDI test
