UWET New Arrival 2000W Uv Lamp Transformers

Product Introduction

V series digital power supply is a high-tech product developed for the driving of gas discharge lamps such as mercury lamps and halogen lamps. It takes high-performance MCU as the control core and high-precision vector control algorithm to ensure the stable output of energy, so as to create excellent curing equipment for customers. This product is widely used in more than 20 fields such as painting, printing, woodworking, PCB, military medical.

 Features

1) Flexible control mode: standard operation panel control, external terminal control, optional RS485 communication control.

2) Rich lighting characteristics: high Voltage mercury lamp, metal halogen lamp parameters are optional.

3) Automatically match the lamp: As long as the rated power of the lamp is set correctly, the power supply automatically compensates for the rated tube Voltage error of the lamp.

4) Automatic compensation for ambient temperature of lamp tube: automatically compensates for the energy drop caused by the exhaust.

5) Status monitoring: This machine comes with LCD human-machine interface to display the working status of the machine and lamp tube in real time.

6) Abundant status signal output: fan control, fault alarm, start-up completion, etc.

7)Standard operation panel is easy to use: start-stop control, power setting, status monitoring, parameter modification, etc.

Specifications

Input

Rated voltage, frequency

three phase(4T#series)380V 50/60Hz

Voltage allowable range

Determined by model

Output

Voltage

 Determined by model

Frequency

8K Hz ~16K Hz

Overload capability

110% 10min

Control Mode

vector control



Control Characteristic

Power setting

Resolution

1%

Current limitation

Power allowable setting

Voltage  limitation

110% of rated lamp tube Voltage

power limitation

Maximum rated output power of the lamp

Under-voltage suppression in operation

Especially for users with low grid voltage and frequent fluctuation of grid voltage, even below the allowable voltage range, the system can maintain the longest running time according to unique algorithm and residual energy allocation strategy.

Typical Function

Standby

 sets standby power consumption when equipment is intermittent for energy-saving applications

Working time record



can read lamp working time in operation

RS485 Communication

Standard Configuration RS485 Communication Interface, Running and Stopping Commands and Machine Status Reading

Operation

Using external Dry Contact Control to Start and Stop

Fault analysis



with function of fault record query and fault cause analysis

Display

Operation panel display

operation

Status

Monitor output voltage, output current, set power, output power, etc.

parameter  setting

Set the relevant parameter values according to actual requirements.



Protection / Alarm

Protection / Alarm of Over current, overvoltage, under voltage, overtemperature, short circuit, internal memory failure

environment

Ambient temperature

-10ºC--+50ºC(not frozen)

Ambient humidity

Below 90%(no frost)

Ambient environment

Indoor (no direct sunlight, no corrosion, no flammable gas, no oil mist, no dust, etc.)



Altitude

Below 1000m

Structure

degree of protection

IP52

Cooling method

Independent air-duct design forced air cooling



Comparison of Various UV Power Supplies




  Transformer +
 Capacitor
Triac Dimming
Power Supply
Traditional stepless
 dimming power supply
V2000 intelligent variable
 frequency power supply
Output frequency 50HZ 50HZ 200HZ-10KHZ 20KHZ
Full power efficiency 80% 80% 90% 98%
Lamp heating Big Big Small Very small
control model Almost no
 control
analog
 control
constant current
 control
Fuzzy Control of Power Vector Algorithms
Harmonic generation Very Large electromagnetic
 interference
Very Large electromagnetic
interference
Very Large electromagnetic
interference
relatively soft
Lighting time 20min 10min Less than 1 min Less than 1 min
Standby switching time Unable to measure Unable to measure Less than 1 min 1 second
Automatic identification
of lamp parameters
No No No Automatically detects the connection status of the lamp and automatically identifies the matching lamp parameters.
Lamp working status No No No More than 20-type protection when lamp parameters are matched
Realization of Touch Screen Control Hard to achieve, and slight significance Hard to achieve, and slight significance Touch screen + PLC + intermediate relay (signal is still analog) Touch screen purely digital communication
(Standard MODEBUS protocol)
Manual operation mode Strict operation sequence
and waiting time
Strict operation seque
nce and waiting time
Strict operation sequence
 and waiting time
 One-button start without any conditions
Power regulation range  Classifi
cations
50%-100% 40%-100% 10%-100%
Power constant factor No No No  Automatic compensation output power



 Trade Show

00



Application

Mainly used in graphic printing industry, UV curing industry, spraying UV curing industry, wood surface treatment and other industries.
