2019 New Arrival 150Mbps ZTE 4g Wifi Hotspot Device
Description
Global Roaming 3G 4G LTE Wi-Fi Universal router gives you high-speed access to the Internet wherever you are and lets you share it on the go. The built-in 4G/3G/2G antennas provides a reliable connection to your 4G/3G/2G service provider. The Harvilon 4G Pocket WiFi provides high-speed Wireless N coverage to give high speed wireless access to everybody whether you are with colleagues on a business trip or traveling with friends and family.
Features
1. pocket wifi router,can support 4G/3G/2G at the same time
2. Our default frequecy are B1/B3 (B2/4/5/B7/B8/12/17/20/28A/28B Optional), products can be used most of country
frequency band also can be customized
3. use Marvell 88MP1802 chipest, good quality, your good choice.
4. DL/ upload 150Mbps/50Mbps.
5. support 10 end users at the same time.
6. support factory price, OEM/ODM is available.
Process/ID | PC+ABS | |
Hardware information Cat4 ZX297520V3 | Remarks | |
The processor | ZX297520V3 | |
spectrum | FDD LTE B1/B3/B5/B8 TDD LTE B38/B39/B40/B41 TD-SCDMA B34/B39 WCDMA B1/B5/B8 | B4/B7/B20/B28ab |
Peak rate | LTE download:100.8Mbps, upload:51.0Mbps (Category 4) TD-SCDMA download:4.2Mbps, upload: 2.2Mbps WCDMA download:42Mbps, upload: 5.76Mbps | |
LED/LCD | LED/LCD | |
The keys | The power button The WPS switch button Restore the factory button (pinhole) | |
T card | Upward compatible to 32 gb | |
WIFI | Support 802.11 b/g/n | |
The battery | 2100 mah lithium battery | |
interface | MicroUSB interface Standard USIM interface MicroSD interface | |
The antenna | built-in | |
The adapter | The input voltage:100V~240V,50Hz~60Hz The output voltage:5V DC±10% The output current:1A | |
Charging interface | Micro 5pin | |
Working temperature | -10°C to 60°C | |
Working humidity | 5% - 65% | |
Storage temperature | -30°C to 80°C | |
Store humidity | 5% to 95% | |
Software information | ||
The operating system | Win7, Windows XP, Vista, Mac OS | |
language | Chinese/English | Support multiple languages |
Shared | Up to 10 users | |
Set up the | support | |
SMS | Support mobile and Unicom conventional card receiving and sending, telecommunication cards do not support | |
The phone book | support | |
APN Settings | support | |
WIFI Settings | support | |
Device Settings | support | |
Routing setting | support | |
Firewall Settings | support | |
certification | Meet customer requirements | |
Other information | ||
size | 59x98x15.5 mm | 98mmX58.5mmX15mm(For reference only) |
The weight of the | 86.04g | |
The standby time | Can reach more than 50 hours | Ultimately decided by the battery |
Work hours | Can reach more than 6 hours (Only connect to one device) | Ultimately decided by the battery |
Our service:
---Your inquiry will be replied in 24hours
---Well-trained and experienced staffs to answer all your inquires in fluent English
---OEM&ODM, for any of your customized products we can help you to design and put into product
---Monthly output over 6,000,000 pcs
---All our products with 12months guarantee
About sample:
---Sample is available.
---Sample lead time: 2-3 working days, 4-5 days with customized logo
---More details, please contact with us.
Payment methods:
---T/T, Western Union, LC.
---30% deposit, balanced before shipment.
Shipping & Trade terms:
---By sea, air, or UPS, FEDEX, EMS, DHL, etc.
---Payment:T/T, Western Union, LC.
---Delivered time: 2-3 business days for sample, 20-25 days for mass order.
